Suzuki SV650AM4(E28) (2024) THROTTLE BODY (SV650AM4 E28) Diagram

Description

Price

BODY ASSY,THROTTLE

13405-18K01

$1,154.57

SCREW

13269-33E00

$11.10

SPRING,THROTTLE SCREW

13268-48700

$4.34

WASHER

13606-47A00

$3.28

O-RING

13295-29901

$4.34

.SENSOR

13580-27G21

$145.53

.O-RING

13575-29G01

$3.15

.SCREW

13605-02F00

$3.71

INJECTOR ASSY

15710-11J00

$271.53

.O-RING

15717-58B00

$9.95

SEAL

15722-29G00

$10.93

HOSE

13683-10F71

$11.10

HOSE

13683-01H01

$10.37

DELIVERY PIPE

15731-11J00

Unavailable

DELIVERY PIPE

15732-11J00

Unavailable

SCREW

13601-11J00

$4.79

PACKING

13602-29G01

$2.43
