Suzuki SV650AM4(E28) (2024) FRONT FENDER (SV650XAM4 E28) Diagram

#

Description

Price

1

FENDER,FRONT (GRAY,BLACK)

53110-18K10-BBT

$90.02

2

.EMBLEM,ABS (GRAY,BLACK)

68151-44G11-BBT

$11.87

3

BOLT (6X19)

09111-06092

$2.62

4

SCREW (6X20)

09139-06190

$4.17

5

CUSHION (9X18X9.5)

09320-09016

$1.97

6

REFLEX REFLECTOR ASSY,FR SIDE

35950-13K01

$12.46

7

BOLT (5X10)

09119-05023

$12.35

8

WASHER

08322-0105B

$2.26
