Suzuki SV650AM4(E28) (2024) ELECTRICAL (SV650AM4 E28) Diagram

#

Description
Price

1

RELAY ASSY,STARTING MOTOR

31800-06G02

$64.39

2

.COVER

31861-47E00

$18.23

3

.FUSE (30A)

09481-30101

$2.35

4

SCREW (6X8)

09128-06013

$1.28

5

RECTIFIER ASSY

32800-47H00

$250.53

6

SCREW This part replaces 02162-0616A.

02162-0616B

$2.13

7

COIL ASSY,IGNITION FRONT

33410-18K00

$148.83

8

BRACKET,IGN COIL REAR

33414-44H01

Unavailable

9

COIL ASSY,IGNITION REAR

33420-18K00

$148.83

10

BOLT (6X20)

09116-06188

$2.25

11

SPACER (6.4X10X18)

09180-06195

$4.70

12

SPACER (6.5X9X9)

09180-06263

$1.68

13

SPACER (6.2X8.4X10.9)

09180-06331

$5.17

14

CUSHION (8X18X10)

09320-08501

$3.06

15

CUSHION (9X18X9.5)

09320-09016

$2.01

16

CLAMP (L:80)

09404-06030

Unavailable

17

CLAMP (L:165)

09407-18402

$2.29

18

BOLT (6X40)

09103-06531

$2.58

19

NUT (6X12)

08316-1006A

$2.25

20

CAP ASSY,SPARK PLUG

33510-17G00

$32.01

21

CAP ASSY,SPARK PLUG | SIDE

33510-17G00

$32.01

22

CAP ASSY,SPARK PLUG | SIDE

33510-20E00

$39.05

23

SEAL,SPARK PLUG

33541-23E10

$6.45

24

SEAL,SPARK PLUG | SIDE

33541-23E10

$6.45

25

SEAL,SPARK PLUG | SIDE

33541-47D00

$7.50

26

SEAL,HIGH TENSION CORD CTR

33542-17G01

$9.17

27

SEAL,HIGH TENSION CORD (SIDE)

33542-38B00

$4.15

28

CONTROL UNIT,FI

32920-18K51

Unavailable

29

SENSOR ASSY,FUEL CUT

33960-06G10

$86.01
