Suzuki SV650AL8 (2018) FRAME COVER (SV650AL8 E33) (FOR AGQ) Diagram

#

Description

Price

1

COVER COMP,FRAM This part replaces 47310-18K00-YSF.

47310-18K01-YSF

$160.61

2

.EMBLEM, "SUZUKI" | (SILVER/BLUE)

68171-28H10-BPD

$8.42

3

CUSHION,FRAME COVER CTR

47315-18K00

$12.73

4

COVER, FRAME REAR RH (WHITE)

47410-18K10-YWW

$113.95

5

.TAPE SET, FRAME COVER RH

68135-18K00-BPC

$27.12

6

COVER, FRAME REAR LH (WHITE)

47510-18K10-YWW

$113.95

7

.TAPE SET, FRAME COVER LH

68145-18K00-BPC

Unavailable

8

BOLT (5X13)

09139-05074

$2.61

9

SPACER (8.5X12X2.5)

09180-08052

Unavailable

10

CLIP This part replaces 09409-06314.

09409-06314-5PK

$2.78

11

BOLT (8X12)

01550-0812A

$2.32

12

SCREW

03541-0510A

$1.49

13

CUSHION (14X20X9) This part replaces 09329-14002.

09329-14003

$2.72

14

PROTECTOR (50X50X5) | CUT AS REQUIRED

33652-20C00

$2.99

15

TAPE,FRAME COVER RR CTR

47312-18K00

$11.53
