Suzuki SV650 (2007) SPEEDOMETER (SV650SK5/SK6/SK7) Diagram

#

Description
Price

1

SPEEDOMETER (MILE/KILO) | MODEL K5/K6

34120-17G80

Unavailable

1

SPEEDOMETER (MILE/KILO) | MODEL K7

34120-17GE0

Unavailable

1

SPEEDOMETER (KILO) | MODEL K5/K6 E28

34120-17G60

Unavailable

1

SPEEDOMETER (KILO) | MODEL K7 E28

34120-17GC0

Unavailable

2

CASE, SPEEDOMETER UPPER

34150-16G00

Unavailable

3

PLATE, SPEEDOMETER

34125-16G00

Unavailable

4

KNOB, SPEEDOMETER

34124-16G00

$9.42

5

CASE, SPEEDOMETER LOWER

34152-16G00

$56.48

6

GASKET, METER CASE

34153-16G00

$15.25

7

CUSHION, SPEEDOMETER

34189-32B00

$5.78

8

CUSHION,SPEEDOMETER This part replaces 34955-13E00.

34955-13E01

$2.92

9

NUT This part replaces 09159-05044.

09159-05049

$2.30

10

SCREW, SPEEDOMETER

34183-16G30

$4.52

11

COVER

34126-16G00

Unavailable

12

GUIDE, SENSOR LEAD

34938-14F00

$6.30

13

RESISTOR ASSY

36510-16G00

Unavailable

14

BOLT (6X25)

09116-06047

Unavailable

15

SENSOR, SPEED | Includes Item(s) 16 - 17

34990-17G30

$258.98

16

SEAL, SENSOR OIL

09286-44001

$11.67

17

MAGNET

34983-27G00

$32.36

18

CLAMP (L:100)

09407-10404

$2.90

19

CLAMP (L:125)

09407-14403

$2.26

20

BOLT This part replaces 01547-06123.

01547-0612B

$1.49
