Description

Price

1

DISC, BRAKE

85G-25711-00-00

Unavailable

2

BODY, CALIPER 2

85G-25741-00-00

Unavailable

3

NUT, SELF-LOCKING

90185-08169-00

$8.49

4

BODY, CALIPER 1

8K4-25731-00-00

Unavailable

5

BOLT, SOCKET

91314-10035-00

Unavailable

6

PAD, CALIPER 2

89J-25811-00-00

$27.99

7

CAM

878-25728-00-00

Unavailable

8

BOLT (8K4)

90101-08499-00

Unavailable

9

NUT, FLANGE

95704-08500-00

$8.49

10

LEVER, BRAKE

878-25726-00-00

Unavailable

11

SPRING, COMPRESSION

90501-23337-00

Unavailable

12

PLATE, BACK UP

878-25733-00-00

Unavailable

13

COVER 1

87B-25715-00-00

Unavailable

14

BOLT, HEXAGON

97017-06012-00

$3.76

15

WASHER, SPRING

92907-06100-00

$4.25

16

WASHER(6TA)

92907-06600-00

Unavailable

Yamaha SV125P (SNOSPORT) 1990 BRAKE Diagram

DISC, BRAKE

BODY, CALIPER 2

NUT, SELF-LOCKING

BODY, CALIPER 1

BOLT, SOCKET

PAD, CALIPER 2

CAM

BOLT (8K4)

NUT, FLANGE

LEVER, BRAKE

SPRING, COMPRESSION

PLATE, BACK UP

COVER 1

BOLT, HEXAGON

WASHER, SPRING

WASHER(6TA)
