Yamaha SV1200A (SUV1200) GU54 2002 OIL TANK Diagram

#

Description
Price

1

TANK, OIL

GU5-U775B-01-00

Unavailable

2

FILTER

F0D-6775C-01-00

$25.74

3

PACKING (T:10MM)

F0D-6775E-01-00

Unavailable

4

PACKING, OIL CAP

GJ3-U778C-00-00

$1.72

5

PACKING, OIL FILLER

GJ3-U778E-00-00

$3.56

6

CAP, OIL FILLER

GJ3-U778B-00-00

Unavailable

7

SOCKET, OIL FILLER

GJ3-U778D-00-00

$4.70

8

CHAIN BALL

EU0-U7835-00-00

$8.32

9

SCREW,TAPPING (EU0)

97780-40110-00

$1.05

10

. RIVET, BLIND

90267-40935-00

$1.28

11

MAT 2

GJ1-U759C-00-00

$30.29

12

SCREW, FLAT HEAD TAPPING

FX1-67869-00-00

$1.36

13

HOSE, OIL FILLER

GU5-U776C-00-00

Unavailable

14

BAND, HOSE 52

90601-152U3-00

$5.67

15

HOSE

FJ0-U2158-00-00

Unavailable

16

HOSE, AIR VENT 3

GP7-U7856-00-00

Unavailable

17

. ROLL OVER VALVE

FJ0-67766-00-00

$54.53

18

CLAMP COMP (EU0)

90600-91736-00

Unavailable

19

CLAMP

90464-32801-00

$1.23

20

RIVET, BLIND

90267-48802-00

$1.98

21

CLAMP

90465-10098-00

$1.68
