Polaris SUPERSPORT EDGE - S04NP5BS/A/B OIL PUMP (2 Way)(Built Before 4/01/03) - S04NP5BS/A/B-S04NE5BS (4988338833D11) Diagram

#

Description
Price

1

Vinyl Pipe 2

3085157

$29.99

1

Vinyl Pipe 2

3085157

$29.99

2

Clamp, Hose

3083141

$1.49

2

Clamp, Hose

3083141

$1.49

2

Clamp, Hose

3083141

$1.49

2

Clamp, Hose

3083141

$1.49

3

Screw, Air Vent

3083125

Unavailable

4

Packing

3083126

$4.03

5

Asm., Oil Pump [Incl. 3-10,16](If built before 4/01/03)

3087208

Unavailable

6

Spring, Return

3087210

Unavailable

7

COLLAR, CAM SHAFT

3083445

$2.39

8

Lever, Control

3087209

Unavailable

9

Washer, Spring

3083121

$299.99

10

Nut

3083120

$3.19

11

Screw and Washer

3083783

$2.39

12

Gear, Small

3083131

$89.99

13

SPACER

3083130

$1.59

14

Bushing, Oil Pump

3083353

$31.99

15

Spacer 3 [.6mm]

3083673

Unavailable

15

Spacer 2 [.3mm]

3083672

Unavailable

15

Spacer 1 [.15mm]

3083671

Unavailable

16

O-Ring

3083127

Unavailable
