Kawasaki STX 160 Fuel Injection Diagram
#
Description
Price
11057
BRACKET,ELECTRIC CASE
11057-0452
$28.92
11057A
BRACKET,ECU&RELAY
11057-2560
$24.47
11061
GASKET
11061-1528
$13.41
21066
REGULATOR-VOLTAGE
21066-0755
$166.56
21175
CONTROL UNIT-ELECTRONIC
21175-1530
$752.02
21176
SENSOR,TEMP
21176-0741
$94.25
26006
FUSE,MINI BLADE,20A,YELLOW
26006-3704
$5.24
26031
HARNESS,MAIN
26031-2609
$588.76
27002
RELAY-ASSY
27002-3703
$51.63
27010
SWITCH,MAGNETIC
27010-0860
$164.03
27010A
SWITCH,VDS
27010-3785
$259.40
59416
CASE-ELECTRIC
59416-3765
$65.38
59416A
CASE-ELECTRIC
59416-3766
$66.70
92002
BOLT,6X12
92002-3763
$4.69
92022
WASHER
92022-3035
$3.52
92022A
WASHER,6.5X20X1.5
92022-3710
$3.65
92026
SPACER
92026-3703
$4.69
92037
CLAMP,L=100
92037-3736
$5.52
92043
PIN
92043-3715
$7.34
92071
GROMMET
92071-3004
$3.99
92071A
GROMMET
92071-3837
$3.23
92072
BAND,L=188.85
92072-0105
$1.73
92072A
BAND,L=372.24
92072-3883
$1.59
92150
BOLT,6X80
92150-3711
$13.04
92173
CLAMP
92173-0742
$9.17
92173A
CLAMP
92173-1578
$8.05
156
BOLT-WP,6X14
156R0614
$3.90
156A
BOLT-WP,6X16
156R0616
$3.65
156B
BOLT-WP,6X18
156R0618
$3.73
156C
BOLT-WP,6X20
156R0620
$3.65
220
SCREW-PAN-CROS,4X20
220R0420
$2.41
311
NUT-HEX,6MM
311R0600
$0.70
410
WASHER-PLAIN-SMALL,10MM
410AA1000
$0.59
410A
WASHER-PLAIN-SMALL,6MM
410S0600
$0.78
