Kawasaki STX-12F Intake Silencer(JT1200-B1) Diagram
#
Description
Price
11011
CASE-AIR FILTER,FR
11011-3703
Unavailable
11011A
CASE-AIR FILTER,RR
11011-3704
$115.63
11053
BRACKET
11053-3725
$29.21
13271
PLATE
13271-3880
$5.00
14073
DUCT,AIR INLET
14073-3794
$17.65
14073A
DUCT,AIR FILTER-THOROTTLE
14073-3795
$5.59
16126
VALVE,AIR SWITCH
16126-1433
$192.78
18020
BAFFLE
18020-3703
$22.48
49006
BOOT,DRAIN
49006-3718
$6.62
52001
TANK-OIL, SEPARETOR
52001-3736
Unavailable
59006
ARRESTER-FLAME
59006-0019
$304.03
59006A
ARRESTER-FLAME
59006-3719
$40.56
92002
BOLT,6X12
92002-3763
$4.69
92009
SCREW,6X20
92009-3870
$4.37
92015
NUT,6MM
92015-3767
$4.69
92022
WASHER,8.2X18X1.5
92022-3743
$4.22
92072
BAND,L=203.2
92072-3867
$1.84
92072A
BAND
92072-3869
$21.83
92093
SEAL
92093-3766
$3.40
92170
CLAMP
92170-3764
$10.35
92171
CLAMP,TUBE
92171-3710
Unavailable
92171A
CLAMP,BOOT
92171-3711
$3.87
92190
TUBE,4X9X450
92190-1062
$13.61
92191
TUBE
92191-3959
Unavailable
92191A
TUBE,ASV-AIR CASE
92191-3960
$25.35
92191B
TUBE,SEPARATOR-AIR CLEANER
92191-3998
Unavailable
92192
TUBE,SEPARATOR-OILPAN
92192-3701
$34.65
92192A
TUBE,HEAD-SEPARATOR
92192-3719
$9.13
132
BOLT-FLANGED-SMALL,6X60
132Y0660
$4.89
155
BOLT-WSP-SMALL,8X20
155R0820
$6.41
156
BOLT-WP,6X16
156R0616
$3.65
