Polaris STANDARD CRUISER - V00CB15DC ELECTRICAL, HARNESSES - V00CB15DC (4952565256B010) Diagram

#

Description
Price

-

HARNESS,RH,R.TURNSIGNAL

2460692

$23.02

-

HARNESS,LH,R.TURNSIGNAL

2460695

$23.02

-

CONNECTOR,8 PIN,R.FENDER

4010153

$13.89

-

LOCK,CONN,8 PIN,R.FENDER

4010154

$1.35

-

HARNESS,INJ/JMPR170-175MM

2460811

Unavailable

-

DECAL,FUSEBOX LAYOUT

7077942

Unavailable

-

HARNESS-WIRE,2000

2460776

Unavailable

1

RELAY,FUEL PUMP

2410098

Unavailable

1

RELAY,FUEL PUMP

2410098

Unavailable

2

FUSE-PARK,20 AMP

2434017

$8.08

2

FUSE-IGNITION,10 AMP

2434016

$5.65

2

FUSE-PARK,20 AMP

2434017

$8.08

2

FUSE-IGNITION,10 AMP

2434016

$5.65

3

DIODE-STARTER CIRCUIT

2434019

$14.83

4

LEAD,SPARK PLUG WIRE

4010130

Unavailable

5

BRKT,VOLTAGE REG,BLK.

1080003-067

Unavailable

6

SCREW,SOCHD,M6X12

7517739

$10.46

7

REGULATOR,VOLTAGE

2410094

Unavailable

8

SCREW,SOCHD,M6X15

7517272

$7.84

9

NUT-HEX-M6X1.0 8 SPC

7547120

$5.22

10

SCREW,HEXHD,M6X20

7517429

$4.76

11

COIL,IGNITION

4010136

Unavailable
