Honda ST1300PAAC (18) MOTORCYCLE, JPN, VIN# JH2SC515-JK600001 TO JH2SC515-JK699999 FRONT FORK Diagram

DUST SEAL, BRAKE CAM (NOK)

45134-KB7-005

$2.83

COLLAR, PIVOT

45452-MZ2-000

$9.24

FORK ASSY., R. FR.

51400-MCS-761

$887.44

SPRING, FR. FORK

51401-MCS-G01

$101.60

COLLAR, SPRING

51402-MCS-G01

$12.38

PLATE, SPRING JOINT

51403-MBR-003

$3.52

PIPE, FR. FORK

51410-MCS-G02

$316.32

RING, BACK-UP

51412-KZ3-003

$8.68

BUSH, GUIDE

51414-MCH-003

$21.08

BUSH, SLIDER

51415-MCS-G01

$5.80

CASE, R. (LOWER)

51420-MCS-G01

$350.15

DAMPER, FR.

51430-MCS-G02

$232.03

PIECE, OIL LOCK

51432-MCS-G01

$16.72

RING, OIL SEAL STOPPER

51447-KZ3-003

$4.88

CAP, FORK PIPE (SHOWA)

51449-MN5-003

$8.37

NUT, HEX. (10MM)

51451-MAJ-G41

$2.68

BOLT, FR. FORK

51454-MCS-G01

$43.00

PROTECTOR, FORK PIPE

51460-MCS-G01

$10.19

SEAL SET, FR. FORK

51490-MCA-003

$33.15

FORK ASSY., L. FR.

51500-MCS-761

$887.44

CASE, L. (LOWER)

51520-MCS-G01

$350.15

BOLT, FLANGE (8X45)

90109-MR7-000

Unavailable

BOLT, SOCKET (8MM)

90117-MCS-G01

$3.19

WASHER, SPECIAL (8MM) (SHOWA)

90544-283-000

$2.65

BEARING, NEEDLE (14X20X20)

91051-MCW-D01

$13.41

DUST SEAL

91254-MCA-003

$7.62

O-RING (37.2X2.4) (SHOWA)

91356-MW0-003

$2.71
