Honda ST1300A (10) MOTORCYCLE, JPN, VIN# JH2SC510-AK800001 SADDLEBAG Diagram

#

Description
Price

1

SPRING, CLUTCH SUB-FREE (AS)

22431-121-880

$1.14

2

RUBBER A, STOPPER

50352-428-000

$2.62

3

RUBBER C, STOPPER

50355-434-000

$4.13

4

SPRING, LOCK KEY SETTING

75581-MAT-D00

$4.13

5

LOCK ASSY., SADDLEBAG LEVER

77227-MCS-G00

$26.25

6

BODY, R. SADDLEBAG *2TN266* (BLACK/MAT BLACK) | Graphite black NHB01;

81201-MCS-G01ZB

$641.70

7

COVER, R. SADDLEBAG *NHB01* (GRAPHITE BLACK) | Graphite black NHB01;

81205-MCS-770ZF

$543.67

8

COVER, R. SADDLEBAG LOCK *2TN266* (BLACK/MAT BLACK) | Graphite black NHB01;

81207-MCS-G01ZB

$17.88

9

LOCK PLATE, R. SADDLEBAG KEY

81208-MCS-G00

$3.16

10

PLATE, SADDLEBAG COVER LOCK

81220-MCS-G00

$2.77

11

GRIP, SADDLEBAG *NH1* (BLACK) | Graphite black NHB01;

81235-MCS-G00ZA

$13.04

12

BRACKET B, SADDLEBAG COVER LOCK

81255-MCS-G00

$5.88

13

LOCK, SADDLEBAG COVER

81260-MCS-G00

$42.35

14

LEVER, R. SADDLEBAG COVER LOCK *NH1* (BLACK) | Graphite black NHB01;

81270-MCS-G00ZA

$10.23

15

SPRING, R. SADDLEBAG LEVER

81274-MCS-G00

$1.50

16

SPRING, SADDLEBAG KEY GUARD

81275-MCS-G00

$2.77

17

BODY, L. SADDLEBAG *2TN266* (BLACK/MAT BLACK) | Graphite black NHB01;

81301-MCS-G01ZB

$670.54

18

COVER, L. SADDLEBAG *NHB01* (GRAPHITE BLACK) | Graphite black NHB01;

81305-MCS-770ZF

$543.67

19

COVER, L. SADDLEBAG LOCK *2TN266* (BLACK/MAT BLACK) | Graphite black NHB01;

81307-MCS-G01ZB

$18.68

20

LOCK PLATE, L. SADDLEBAG KEY

81308-MCS-G00

$3.32

21

PLATE, HINGE SETTING

81318-MCS-G00

$1.50

22

PLATE, HINGE SETTING

81318-MT3-000

$2.63

23

RUBBER, PLATE

81319-MCS-G00

$1.24

24

CUSHION, SADDLEBAG

81327-MT3-000

$4.23

25

LEVER, L. SADDLEBAG COVER LOCK *NH1* (BLACK) | Graphite black NHB01;

81370-MCS-G00ZA

$12.22

26

SPRING, L. SADDLEBAG LEVER

81374-MCS-G00

$2.29

27

STOPPER, SADDLEBAG COVER

81380-MCS-G00

$23.52

28

NUT, MOLDING SIDE

90305-SJ4-003

$3.91

29

WASHER, THRUST (5MM)

90504-964-000

$1.72

30

SCREW, TAPPING (4X6)

93903-24080

$0.63

31

SCREW, TAPPING (4X12)

93903-24380

Unavailable

32

SCREW, TAPPING (4X25)

93903-44680

$0.32

33

WASHER, PLAIN (4MM)

94103-04700

$0.86

34

BALL, STEEL (#7) (7/32)

96211-07000

$1.16
