Honda ST1100AA (94) ABS-TCS, JPN, VIN# JH2SC263-RM400001 STEP Diagram

#

Description
Price

1

SPRING, KICK STARTER STOPPER

28333-300-000

$2.80

2

RUBBER, STAND STOPPER

50505-MT3-010

Unavailable

4

HOLDER, R. STEP

50600-MY3-780

Unavailable

5

COLLAR, MOUNTING RUBBER

50607-KK6-000

$8.20

6

RUBBER, MUFFLER SETTING

50608-KV0-000

$5.80

7

ARM, R. STEP (COO) This part replaces 50612-MT3-000.

50612-MT3-305

$40.84

8

COLLAR (5.0)

50613-MT3-000

$2.71

9

SPRING, R. STEP RETURN

50617-MM5-000

$4.47

10

PLATE, STEP SETTING

50619-MT3-000

$10.87

11

RUBBER, STEP HOLDER

50622-MM5-000

$4.03

13

PIN, STEP BAR

50639-ML0-010

Unavailable

15

ARM, L. STEP (COO) This part replaces 50642-MT3-000.

50642-MT3-305

$40.84

16

SPRING, L. STEP RETURN

50644-MM5-000

$4.47

17

RUBBER, STEP (COO) This part replaces 50661-MT3-000.

50661-MT3-305

$6.74

18

HOLDER, L. STEP

50700-MT3-000

Unavailable

19

BAR, R. PILLION STEP (COO) This part replaces 50711-MT3-000.

50711-MT3-305

$53.39

19

BAR, R. PILLION STEP (COO) This part replaces 50711-MT3-010.

50711-MT3-305

$53.39

20

BAR, L. PILLION STEP (COO) This part replaces 50712-MT3-000.

50712-MT3-305

$49.63

20

BAR, L. PILLION STEP (COO) This part replaces 50712-MT3-010.

50712-MT3-305

$49.63

21

PLATE, PILLION STEP CLICK

50718-MT3-000

$4.23

24

BOLT, SPECIAL (10X36)

90104-MT3-000

$9.77

25

BOLT, SPECIAL (8X10)

90115-MM5-000

$11.16

26

BOLT, MAIN STEP RUBBER SETTING

90115-MT3-000

$2.46

27

BOLT, CAP (8X16)

92501-08016-0A

$2.38

28

WASHER, PLAIN (6MM) This part replaces 94101-06000.

94101-06800

Unavailable

28

WASHER, PLAIN (6MM) This part replaces 94101-06080.

94101-06800

Unavailable

28

WASHER, PLAIN (6MM)

94101-06800

Unavailable

29

WASHER, PLAIN (8MM)

94101-08000

$0.75

30

PIN, COTTER (1.6X12)

94201-16120

$0.94

31

PIN, COTTER (2.0X15)

94201-20150

$0.94

32

PIN C, PILLION FOOTPEG

95015-83000

$2.19

33

BALL, STEEL (#8) (1/4)

96211-08000

$1.13
