Honda ST1100AA (02) MOTORCYCLE, JPN, VIN# JH2SC263-2M300001 STEP Diagram

#

Description
Price

1

SPRING, KICK STARTER STOPPER

28333-300-000

$2.80

2

RUBBER, STAND STOPPER

50505-MT3-010

Unavailable

4

HOLDER, R. STEP

50600-MAJ-G41

Unavailable

5

COLLAR, MOUNTING RUBBER

50607-KK6-000

$8.20

6

RUBBER, MUFFLER MOUNTING

50608-KV0-000

$5.80

7

ARM, R. STEP (COO) This part replaces 50612-MT3-000.

50612-MT3-305

$40.84

8

COLLAR (5.0)

50613-MT3-000

$2.71

9

SPRING, R. STEP RETURN

50617-MM5-000

$4.47

10

PLATE, STEP SETTING

50619-MT3-000

$10.87

11

RUBBER, STEP HOLDER

50622-MM5-000

$4.03

12

PIN, STEP BAR

50639-ML0-010

Unavailable

13

ARM, L. STEP (COO) This part replaces 50642-MT3-000.

50642-MT3-305

$40.84

14

SPRING, L. STEP RETURN

50644-MM5-000

$4.47

15

RUBBER, STEP (COO) This part replaces 50661-MT3-000.

50661-MT3-305

$6.74

16

HOLDER, L. STEP

50700-MAJ-G21

$232.75

17

BAR, R. PILLION STEP (COO) This part replaces 50711-MT3-000.

50711-MT3-305

$53.39

17

BAR, R. PILLION STEP (COO) This part replaces 50711-MT3-010.

50711-MT3-305

$53.39

17

BAR, R. PILLION STEP (COO)

50711-MT3-305

$53.39

18

BAR, L. PILLION STEP (COO) This part replaces 50712-MT3-000.

50712-MT3-305

$49.63

18

BAR, L. PILLION STEP (COO) This part replaces 50712-MT3-010.

50712-MT3-305

$49.63

18

BAR, L. PILLION STEP (COO)

50712-MT3-305

$49.63

19

PLATE, PILLION STEP CLICK

50718-MT3-000

$4.23

20

BOLT, SPECIAL (10X36)

90104-MT3-000

$9.77

21

BOLT, SPECIAL (8X10)

90115-MM5-000

$11.16

22

BOLT, MAIN STEP RUBBER SETTING

90115-MT3-000

$2.46

23

BOLT, CAP (8X16)

92501-08016-0A

$2.38

24

WASHER, PLAIN (6MM) This part replaces 94101-06000.

94101-06800

Unavailable

24

WASHER, PLAIN (6MM) This part replaces 94101-06080.

94101-06800

Unavailable

24

WASHER, PLAIN (6MM) (USED ON TAILLIGHT)

94101-06800

Unavailable

25

WASHER, PLAIN (8MM)

94101-08000

$0.75

26

PIN, COTTER (1.6X12)

94201-16120

$0.94

27

PIN, COTTER (2.0X15)

94201-20150

$0.94

28

PIN C, PILLION FOOTPEG

95015-83000

$2.19

29

BALL, STEEL (#8) (1/4)

96211-08000

$1.13
