Description

Price

1

OIL PUMP ASSY

8DN-13100-00-00

Unavailable

2

BOLT,SOCKET

91317-05014-00

$8.49

3

O-RING(3SB)

93210-20712-00

$4.29

4

PUMP CABLE ASSEMBLY

8DF-26320-00-00

Unavailable

5

NUT, NYLON

95717-08300-00

$2.70

6

TUBE, FLEXIBLE VINYL(8AV)

91A30-03039-00

$10.49

7

TUBE, FLEXIBLE VINYL(8AV)

91A30-03039-00

$10.49

8

SPRING, COMPRESSION (10L)

90501-08668-00

$11.49

9

. JOINT

8H0-24379-00-00

Unavailable

10

SPRING, COMPRESSION

90501-06028-00

Unavailable

11

TUBE, FLEXIBLE VINYL(8AV)

91A30-03039-00

$10.49

12

TUBE,FLEXIBLE VINYL(85R)

91A30-05080-00

$18.99

13

HOSE

90445-136E2-00

Unavailable

14

CLAMP

90462-08237-00

Unavailable

15

HOSE

91A30-07036-00

Unavailable

16

SPRING, COMPRESSION(1YU)

90501-061E8-00

Unavailable

17

BOLT, BREATHER

8DF-13185-00-00

Unavailable

18

. GASKET, BREATHER BOLT

8DF-13187-00-00

Unavailable

19

BOLT 1

8DF-13573-00-00

Unavailable

20

SPRING, COMPRESSION(3JK)

90501-101J5-00

Unavailable

21

TUBE, FLEXIBLE VINYL(8AV)

91A30-03039-00

$10.49

22

CHECK VALVE

8CH-1316A-00-00

Unavailable

23

CLIP (2A6)

90468-02025-00

Unavailable

24

CLIP (8A1)

90467-09026-00

Unavailable

25

CLIP (2A6)

90468-02078-00

Unavailable

26

CLIP (7K7)

90467-11044-00

Unavailable

Yamaha SRX700SB (SRX700S (OHLINS FR SHOCKS)) 8DW1 1998 OIL PUMP Diagram

OIL PUMP ASSY

BOLT,SOCKET

O-RING(3SB)

PUMP CABLE ASSEMBLY

NUT, NYLON

TUBE, FLEXIBLE VINYL(8AV)

TUBE, FLEXIBLE VINYL(8AV)

SPRING, COMPRESSION (10L)

. JOINT

SPRING, COMPRESSION

TUBE, FLEXIBLE VINYL(8AV)

TUBE,FLEXIBLE VINYL(85R)

HOSE

CLAMP

HOSE

SPRING, COMPRESSION(1YU)

BOLT, BREATHER

. GASKET, BREATHER BOLT

BOLT 1

SPRING, COMPRESSION(3JK)

TUBE, FLEXIBLE VINYL(8AV)

CHECK VALVE

CLIP (2A6)

CLIP (8A1)

CLIP (2A6)

CLIP (7K7)
