Yamaha SRX600SB (SRX600S (OHLINS FR SHOCKS)) 1998 CYLINDER HEAD Diagram
#
1
HEAD, CYLINDER 1
8DF-11111-00-00
Unavailable
2
BR10ECS NGK SPLUG 10PK
BR1-0ECS0-00-00
Unavailable
3
SEAL, CYLINDER 1
8DF-11355-00-00
$14.49
4
O-RING(1LX)
93211-07720-00
$12.49
5
PIN, DOWEL(3VD)
99530-10114-00
$2.55
6
BOLT, FLANGE
95817-08055-00
$4.21
7
BOLT, WASHER BASED
90105-084A1-00
$10.49
8
WASHER, PLATE
90201-080L8-00
$4.41
9
CYLINDER 1
8DF-11311-01-00
Unavailable
10
GASKET, CYLINDER
8DF-11351-00-00
$82.99
11
PIN, DOWEL
99530-14016-00
$3.80
12
NUT, FLANGE(8AB)
95707-10500-00
$3.18
13
BOLT, STUD (26H)
90116-10411-00
$13.49
14
BOLT, STUD(1JK)
90116-10506-00
$4.77
15
VALVE 1
8DF-1131A-00-00
Unavailable
16
HOLDER 1
8DF-1131E-00-00
Unavailable
17
GASKET
8DF-11354-03-00
Unavailable
18
HOLDER 2
8DF-1131F-01-00
Unavailable
19
OIL SEAL
93109-15074-00
Unavailable
20
SEAT, SPRING
8DF-11317-01-00
Unavailable
21
SPRING, COMPRESSION
90501-120L7-00
Unavailable
22
GASKET
8DF-11397-10-00
Unavailable
23
HOLDER 3
8DF-1131U-01-00
Unavailable
24
WASHER, PLATE
90201-092U3-00
Unavailable
25
CIRCLIP(53L)
99001-06600-00
Unavailable
26
O-RING (1J7)
93210-09350-00
Unavailable
27
BOLT, SOCKET
91317-05016-00
Unavailable
28
WIRE PULLEY 1
8DF-1133E-01-00
Unavailable
29
CABLE, PULLEY 2
8DF-1133F-01-00
Unavailable
30
CLAMP
90464-06253-00
Unavailable
