Yamaha SRX1NSL (SRX120R) 8MVA 2025 EXHAUST Diagram

#

Description
Price

1

PANEL, SUB FRAME 3

8MV-F1914-50-00

Unavailable

2

SHIELD, HEAT

8MV-F199H-00-00

Unavailable

3

TAPE,REFLECTOR

8MY-H5133-00-00

$16.79

4

SILENCER ASSY

8JM-E4750-00-00

Unavailable

5

RIVET, 5

8JP-RA514-00-00

Unavailable

6

SPRING, EXTENSION

8JM-RAD04-00-00

$5.22

7

PROTECTOR, MUFFLER 1

8JM-E4718-00-00

Unavailable

8

STAY, MUFFLER

8JM-F194J-00-00

Unavailable

9

RIVET, BLIND-LF SS56 BLACK

8JM-RA502-00-00

Unavailable

10

PLATE 1

8MV-K8181-00-00

Unavailable

11

SCREW, 10-12X3/4

8KC-RA290-00-00

$1.62

12

RIVET, BLIND 4

8JM-RA503-00-00

$0.39

13

BOOT, TIE ROD-RH

8JM-F198G-00-00

Unavailable

14

COVER 1

8JM-F198F-00-00

Unavailable

15

RIVET, 16

8LN-RA525-00-00

$1.02

16

NUT, CLIP 10

8JP-RA352-00-00

Unavailable
