Yamaha SR643 1975 FRONT AXLE Diagram

#

Description

Price

1

FRONT AXLE

(836-47510-00-00)

Unavailable

2

WHEEL, SPROCKET 1

(836-47531-00-00)

Unavailable

2

COLLAR

(90387-06021-00)

Unavailable

4

RIM, SPROCKET WHL 2

(836-47522-00-00)

Unavailable

5

BOLT (682)

97095-06040-00

$1.86

6

WASHER, LOCK

90215-06100-00

Unavailable

7

WHEEL, GUIDE 2

(836-47535-00-00)

Unavailable

8

PLATE

(836-47519-00-00)

Unavailable

9

PIN, SPRING

91609-60036-00

Unavailable

10

OIL SEAL,SD-TYPE

93102-25332-00

Unavailable

11

BEARING

93306-00412-00

Unavailable

12

CIRCLIP, R-TYPE

93420-44029-00

Unavailable

13

HOUSING, FRONT AXLE

810-47551-00-00

Unavailable

14

BOLT, HEXAGON

97017-06025-00

$4.24

14

BOLT, HEXAGON W/W DEEP RECESS

97E95-06555-00

Unavailable

15

WASHER, SPRING

92995-06100-00

Unavailable

16

WASHER 810475810000

90208-22001-00

Unavailable

17

NUT (821-47579-00)

90170-22094-00

Unavailable
