Yamaha SR10SD37GR (SRVIPER S TX DX 137) 8LJ1 2016 CAMSHAFT CHAIN Diagram

#

Description
Price

1

CAMSHAFT ASSY 1

8KH-12170-00-00

$239.33

2

CAMSHAFT ASSY 2

8KH-12180-00-00

$237.11

3

SPROCKET, CAM CHAI

2HC-12176-00-00

$31.93

4

BOLT, FLANGE

90105-07004-00

$4.66

5

CHAIN

94591-57140-00

$33.34

6

TENSIONER ASSY, CA

8KH-12210-00-00

$95.58

7

GASKET, TENSIONER CASE

2C0-12213-00-00

$6.29

8

BOLT, HEXAGON SOCKET HEAD

90110-06335-00

$4.82

9

DAMPER, CHAIN 1

8GL-12251-01-00

$23.06

10

DAMPER, CHAIN 2

2HC-12252-00-00

$57.05

11

BOLT

90109-06297-00

$4.81
