Description

Price

1

PANEL, INSTRUMENT

8JP-K7712-00-00

Unavailable

2

SCREW, 10-12X3/4

8KC-RA290-00-00

$1.86

3

SRVIPER GOGGLE HOLDER BAG

SMA-8JP53-00-00

Unavailable

4

SCREW, M6-1.0X18

8JP-RA253-00-00

$1.86

5

PANEL, INSTRUMENT (DEEP PURPLISH BLUE SOLID E)

8KN-K7711-40-00

Unavailable

6

SCREW, M6-1.0X15

8JP-RA252-00-00

Unavailable

7

SWITCH (HEATER)

8JP-H2627-00-00

$78.99

8

NUT

8JP-K6169-00-00

Unavailable

9

WASHER, TOOTH 1

8JP-RA471-00-00

Unavailable

10

STOP SWITCH ASSY

8KN-H2551-00-00

$44.99

11

. CAP, SWITCH

8KN-H2552-00-00

Unavailable

12

.. SCREW, TAPPING

8KN-RA291-00-00

Unavailable

13

NUT, CLIP 10

8JP-RA352-00-00

$1.64

14

PANEL, INSTRUMENT

8JP-K7713-00-00

Unavailable

15

. LABEL, WARNING 1

8JP-K7761-70-00

Unavailable

16

. LABEL, WARNING 1

8JP-K7761-S0-00

Unavailable

17

PROTECTOR, SIDE

8JP-K7561-01-00

Unavailable

18

. VELCRO (6.5 FEET)

8JP-R4261-00-00

Unavailable

19

NUT, 1

8JP-RA345-00-00

Unavailable

20

PIN, 2

8JP-RAK02-00-00

Unavailable

Yamaha SR10RLGW (SRVIPER R TX LE) 8KN40 2016 INSTRUMENT PANEL Diagram

PANEL, INSTRUMENT

SCREW, 10-12X3/4

SRVIPER GOGGLE HOLDER BAG

SCREW, M6-1.0X18

PANEL, INSTRUMENT (DEEP PURPLISH BLUE SOLID E)

SCREW, M6-1.0X15

SWITCH (HEATER)

NUT

WASHER, TOOTH 1

STOP SWITCH ASSY

. CAP, SWITCH

.. SCREW, TAPPING

NUT, CLIP 10

PANEL, INSTRUMENT

. LABEL, WARNING 1

. LABEL, WARNING 1

PROTECTOR, SIDE

. VELCRO (6.5 FEET)

NUT, 1

PIN, 2
