Yamaha SR10RLFO (SRVIPER R TX LE) 8KN1 2015 INSTRUMENT PANEL Diagram

#

Description
Price

1

PANEL, INSTRUMENT

8JP-K7712-00-00

Unavailable

2

SCREW, 10-12X3/4

8KC-RA290-00-00

$1.86

3

LOUVER 1

8JP-K7131-00-00

Unavailable

4

SCREW, M6-1.0X18

8JP-RA253-00-00

$1.86

5

PANEL, INSTRUMENT

8KN-K7711-20-00

Unavailable

6

SCREW, M6-1.0X15

8JP-RA252-00-00

Unavailable

7

NUT

8JP-K6169-00-00

Unavailable

8

WASHER, TOOTH 1

8JP-RA471-00-00

Unavailable

9

STOP SWITCH ASSY

8KN-H2551-00-00

$44.99

10

. CAP, SWITCH

8KN-H2552-00-00

Unavailable

11

.. SCREW, TAPPING

8KN-RA291-00-00

Unavailable

12

NUT, CLIP 10

8JP-RA352-00-00

$1.64

13

PANEL, INSTRUMENT

8JP-K7713-00-00

Unavailable

14

. LABEL, WARNING 1

8JP-K7761-70-00

Unavailable

15

. LABEL, WARNING 1

8JP-K7761-S0-00

Unavailable

16

PROTECTOR, SIDE

8JP-K7561-01-00

Unavailable

17

. VELCRO (6.5 FEET)

8JP-R4261-00-00

Unavailable

18

NUT, 1

8JP-RA345-00-00

Unavailable

19

PIN, 2

8JP-RAK02-00-00

Unavailable
