Description

Price

1

PIPE, CROSS 6

8JP-F119A-00-00

$44.99

2

. NUT, HEXAGON

8JP-RA331-00-00

Unavailable

3

CLAMP, 5

8JP-RAB07-00-00

Unavailable

4

SCREW, M5X1.0X16

8JP-RA251-00-00

$0.43

5

BOLT, FLG. M8X1.25

8JP-RA187-00-00

Unavailable

6

CAP, MAIN PIPE

8JP-F111A-20-00

$5.49

7

NUT, HEX. LOCKING

8JP-RA372-00-00

$0.54

8

BOLT, FLG. M6X1.0X

8JP-RA182-00-00

$0.75

9

WASHER,LOCK-1/4 EXT TOOTH TYP

8JM-RA407-00-00

$0.27

10

NUT,FLG. M6-1.0

8JM-RA322-00-00

$1.07

11

GUSSET

8JP-F1113-10-00

Unavailable

12

BRACKET 5

8JP-F112K-00-00

$28.99

13

MEMBER, SIDE 1

8JP-F111J-00-00

$154.99

14

MEMBER, SIDE 2

8JP-F111K-00-00

Unavailable

15

BOLT, FLG. M8X1.25

8JP-RA185-00-00

$0.96

16

SCREW, 10-12X1.00

8KC-RA288-00-00

Unavailable

17

CLIP

8JP-F11C2-00-00

Unavailable

18

SCREW, M6X1.0X30

8JP-RA266-00-00

Unavailable

19

BOLT, FLANGE M8-1.25X25

8JM-RA102-00-00

Unavailable

20

NUT,HEX FLG-NYL LOCK M8X1.25

8JM-RA301-00-00

Unavailable

21

GATE, STEERING

8JP-F3871-00-00

Unavailable

22

PIPE, CROSS, 7

8JP-F119E-00-00

Unavailable

23

PIPE CROSS 8

8JP-F119F-00-00

Unavailable

24

. SUPPORT, SEAT

8JP-F114H-00-00

Unavailable

25

RIVET, 5

8JP-RA514-00-00

Unavailable

26

INSERT

8JP-F3775-00-00

Unavailable

Yamaha SR10M62SFR (SRVIPER M TX 162 SE) 8KT10 2015 STEERING GATE Diagram

PIPE, CROSS 6

. NUT, HEXAGON

CLAMP, 5

SCREW, M5X1.0X16

BOLT, FLG. M8X1.25

CAP, MAIN PIPE

NUT, HEX. LOCKING

BOLT, FLG. M6X1.0X

WASHER,LOCK-1/4 EXT TOOTH TYP

NUT,FLG. M6-1.0

GUSSET

BRACKET 5

MEMBER, SIDE 1

MEMBER, SIDE 2

BOLT, FLG. M8X1.25

SCREW, 10-12X1.00

CLIP

SCREW, M6X1.0X30

BOLT, FLANGE M8-1.25X25

NUT,HEX FLG-NYL LOCK M8X1.25

GATE, STEERING

PIPE, CROSS, 7

PIPE CROSS 8

. SUPPORT, SEAT

RIVET, 5

INSERT
