Sea-doo Sportster LE DI, 2006 Air Intake Diagram

#

Description
Price

1

AIR SILENCER ADAPTOR - Call your local BRP dealership

270600023

Unavailable

2

Hex. Screw M4 X 12, Scotch Grip

207341260

Unavailable

3

Flat Washer 4 mm, Stainless

234042600

$1.15

4

INTAKE HOSE - Call your local BRP dealership

270600021

Unavailable

5

Tubing 25 MM 1000MM Long

219704402

$15.99

6

Tie Wrap 142 mm

293750002

$1.25

7

Tridon Gear Clamp

293650172

$3.09

8

Tridon Gear Clamp

293650173

$3.09

9

Flat Washer 8 mm, Stainless

234082600

$2.43

10

Loctite 243, 10 ml

293800060

$21.49

11

HEX. SCREW M8 X 12 - Call your local BRP dealership

207181260

Unavailable

12

Flat Washer M6, Stainless

234062600

$0.77

13

Flat Washer M6, Stainless

234062600

$0.77

14

Hex. Elastic Stop Nut M6

232561600

$1.15

15

SPACER - Call your local BRP dealership

272000074

Unavailable

16

UPPER INSULATOR - Call your local BRP dealership

278001260

Unavailable

17

Hex. Screw M6 X 35

207063560

$2.22

18

Air Silencer | Includes 18 to 21

273000209

Unavailable

19

Not Available As Spare Part - Friction Washer

Unavailable

20

Was 415080100 Fuel Line Primer 3,2mm

219704409

$79.49

21

CONNECTOR - Call your local BRP dealership

293710107

$1.09

22

SUPPORT PLATE - Call your local BRP dealership

273000204

Unavailable

23

Cable Grommet

293720052

Unavailable

24

INTAKE ADAPTOR, PTO - Call your local BRP dealership

273000163

Unavailable

25

INTAKE ADAPTOR, MAG - Call your local BRP dealership

273000164

Unavailable

26

GROMMET - Call your local BRP dealership

293720064

Unavailable

27

CHECK VALVE - Call your local BRP dealership

275500454

Unavailable

28

Gasket

293250122

$67.99

29

FEMALE ADAPTOR - Call your local BRP dealership

270600024

Unavailable

30

HIGH AIR DUCT, PTO - Call your local BRP dealership

273000151

Unavailable

31

High Air Duct, Mag

273000150

Unavailable

32

HAIR PIN - Call your local BRP dealership

250400015

Unavailable

33

PROTECTOR PAD - Call your local BRP dealership

273000165

Unavailable

34

HOSE 4.3 MM - Call your local BRP dealership

270000471

Unavailable

35

Tie Wrap 94 mm | 4X4

293750001

$1.03

36

Oetiker Clamp

293650100

$3.38

37

T-Fitting

293710068

$8.29

38

HOSE 4.3 MM - Call your local BRP dealership

270000471

Unavailable

39

HOSE 4.3 MM - Call your local BRP dealership

270000471

Unavailable

40

Oetiker Clamp

293650100

$3.38

41

HOSE 4.3 MM - Call your local BRP dealership

270000471

Unavailable

42

Oetiker Clamp

293650100

$3.38

43

Check Valve

275500398

$10.99

44

Was 420660574 Pressure Hose 280 mm

219704352

$224.99

45

Tie Wrap 94 mm | 4X4

293750001

$1.03

46

Was 420660574 Pressure Hose 280 mm

219704352

$224.99

47

Oetiker Clamp

293650100

$3.38

48

Tie Wrap 94 mm | 4X4

293750001

$1.03

49

T-Fitting

293710068

$8.29

50

SOLENOID VALVE - Call your local BRP dealership

270600044

Unavailable

51

Flat Washer M5, Stainless

234051600

$0.77

52

Hex. Elastic Nut M5 | X

232551600

$1.15

53

Was 420660574 Pressure Hose 280 mm

219704352

$224.99

54

Tie Wrap 94 mm | 4X4

293750001

$1.03

55

Was 420660574 Pressure Hose 280 mm

219704352

$224.99

56

Oetiker Clamp

293650100

$3.38

57

Tie Wrap 94 mm | 4X4

293750001

$1.03
