01- Engine Support And Muffler
Sea-doo Sportster, 5614, 1998 01- Engine Support And Muffler Diagram
#
1
Hex. Nut M8
232081600
$1.47
2
Flat Washer M8.5 x 18
293050001
$3.07
3
Tuned Pipe Ass'y
274000487
Unavailable
4
Stud M8 x 26
420941014
$14.22
5
Exhaust Gasket This part replaces 290950253.
420950253
$14.83
6
Exhaust Manifold (White)
290979141
Unavailable
7
Gasket This part replaces 290850638.
420850638
$12.17
8
Rotax Engine 717(White)
270000379
Unavailable
9
Engine Support
270000312
Unavailable
10
Lock Spring Washer 8 mm, Stainless
234180602
$1.16
11
Helicoidal Lock Washer M10 | XT Models
234101601
$1.15
12
HEX. NUT M10 - Call your local BRP dealership
232001600
Unavailable
13
Hex. Flange Screw M8 x 68.5
290841998
Unavailable
14
Shim 0.4 mm
270000006
Unavailable
Shim 1.3 mm
270000007
Unavailable
Shim 3.3 mm
270000143
Unavailable
15
SHIM 0.4 MM - Call your local BRP dealership
270000024
Unavailable
SHIM 1.3 MM - Call your local BRP dealership
270000025
Unavailable
16
Rubber Mount
270000425
$71.99
17
Flat Washer 8 mm, Stainless
234082600
$2.43
18
HEX. SCREW M8 X 20 - Call your local BRP dealership
207182060
Unavailable
19
Hex. Screw M8 X 30
207183060
$1.58
20
Flat Washer 10 mm, Stainless
234001600
$1.15
21
Gasket
274000276
Unavailable
22
Norma Clamp
293650079
$11.60
23
Norma Clamp
293650077
$7.41
24
NORMA CLAMP - Call your local BRP dealership
293650076
Unavailable
25
Hose Adaptor
274000383
Unavailable
26
Tridon Clamp
293650064
$8.29
27
Muffler
274000491
Unavailable
28
Retainer Strap
293850097
$11.64
29
Exhaust Hose
274000170
Unavailable
30
STRAP CLIP - Call your local BRP dealership
293850024
Unavailable
31
Pop Rivet 3/16"
293150008
$0.50
32
Loctite 243, 10 ml
293800060
$21.49
33
Stainless, Flat Washer 8 mm
234081600
$0.55
34
NORMA CLAMP - Call your local BRP dealership
293650068
Unavailable
35
Sealing Ring
274000074
Unavailable
36
Exhaust Cone Ass’Y
274000488
Unavailable
37
Rubber Pad
293830055
Unavailable
38
Black, Dart
293730006
$0.99
39
Hex. Screw M8 X 30
207183060
$1.58
40
Bushing
274000114
$8.85
41
Rubber Bushing
293830031
Unavailable
42
Hex. Screw M8 X 40
207084060
$2.22
43
Hex. Elastic Stop Nut M6
232561600
$1.15
44
Exhaust Hose
204340074
Unavailable
45
Hex. Screw M6 X 25
207162560
$1.47
46
Stainless Flat Washer M6
234061600
$0.33
47
Ring
274000277
Unavailable
48
T Fitting
204340064
Unavailable
49
Resonateur
204340065
Unavailable
50
Exhaust Hose
204340075
Unavailable
51
LH Expansion Chamber
204340060
Unavailable
52
Engine Gasket Set (Not Shown)
290886317
Unavailable
53
CYLINDER GASKET SET (NOT SHOWN) - Call your local BRP dealership
290886316
Unavailable
