Polaris SPORTSMAN 800 EFI 6X6 - A12CF76AA BODY, DUMP BOX - A12CF76AA (49ATVBOX096X6) Diagram

#

Description
Price

1

SCREW

7515177

$3.19

2

WASHER

7558221

$2.39

3

ROD, HINGE

5132358

$51.99

4

TAILGATE

5433388

$375.99

5

SCREW

7517561

$1.59

5

SCREW

7517561

$1.59

5

SCREW

7517561

$1.59

5

SCREW

7517561

$1.59

6

LATCH

5433656

$63.99

7

LATCH, PADDLE

5433655

$83.99

8

PIN, HITCH

7661644

$2.39

9

WASHER, RUBBER

7556143

$4.79

10

SHAFT, LATCH

5132373

$11.99

11

ASM., BACKREST, BLACK [INCL. COVER]

2684915-070

$179.99

12

Bracket, Box Latch

5243304

$14.39

13

Screw

7517938

$1.49

14

Ring, Tie Down

7081101

$7.99

15

GUARD, MUD, BOX, BLACK, LH

5437873-070

$136.39

16

SCREW

7517742

$5.59

17

Cable, Tailgate

7080881

$39.99

18

Cover, Tailgate, Black

5244068-067

$27.99

19

BOX, MOLDED, BLACK [INCL. WARNING DECAL]

5439200

$765.37

20

DECAL-REFLECT.2.88,RED

7079925

$7.19

20

DECAL-REFLECT.2.88,RED

7079925

$7.19

21

SCREW

7517686

$1.59

22

GUARD, MUD, BOX, BLACK, RH

5437874-070

$136.39

23

SUPPORT, BOX, BLACK

1016881-067

$564.99

24

SCREW

7519047

$3.99

24

SCREW

7519047

$3.99

25

Screw

7518196

$1.49
