INTAKE and EXHAUST - A06MH50AQ/AX/AY/AZ/AL/AT (4999200099920009D09)
Polaris SPORTSMAN 500 EFI - A06MH50AQ INTAKE and EXHAUST - A06MH50AQ/AX/AY/AZ/AL/AT (4999200099920009D09) Diagram
#
Description
Price
1
PLUG
3087129
Unavailable
2
GASKET, PLUG
3087130
$11.19
3
SPRING, TENSIONER
3087131
Unavailable
4
PIN
3087132
$10.39
5
Asm., Tensioner [Incl. 1-4]
3086493
Unavailable
6
Nut
3084912
$3.99
6
Nut
3084912
$3.99
6
Nut
3084912
$3.99
7
Screw, Adjusting
3084911
$9.59
7
Screw, Adjusting
3084911
$9.59
7
Screw, Adjusting
3084911
$9.59
8
ASM., ROCKER ARM, INTAKE [INCL. 6,7]
3084910
$115.99
8
ASM., ROCKER ARM, INTAKE [INCL. 6,7]
3084910
$115.99
9
SHAFT, ROCKER
3084909
$51.99
10
Asm., Rocker Arm, Exhaust [Incl. 6,7]
3084913
$131.99
11
VALVE, COLLET
3084908
$3.99
11
VALVE, COLLET
3084908
$3.99
12
RETAINER, SPRING
3087203
Unavailable
12
RETAINER, SPRING
3087203
Unavailable
13
Spring, Valve
3084906
Unavailable
13
Spring, Valve
3084906
Unavailable
14
PIN, DOWEL
3086838
$7.19
15
LEVER, RELEASE
3085348
Unavailable
16
SPRING, RETURN
3085076
Unavailable
17
Camshaft [Incl. 14-18]
3085855
$303.99
18
PIN, DOWEL
3084899
$7.19
19
SPROCKET 2
3084914
$75.99
20
GUIDE, CHAIN
3084916
Unavailable
21
ASM., BOLT AND WASHER
3081657
$4.79
22
CHAIN, TIMING
3084915
$95.99
23
ASM., BOLT, PIVOT LEVER
3084924
Unavailable
24
LEVER
3084917
$91.99
25
VALVE, INTAKE
3085349
$63.99
26
VALVE, EXHAUST
3085412
$87.99
27
GASKET, TENSIONER
3086448
$6.39
28
BOLT, FLANGE
3083361
Unavailable
