Polaris SPORTSMAN 400 - A01CH42AB INTAKE and EXHAUST - A01CH42AA (4964436443D004) Diagram

#

Description
Price

1

PLUG

3084845

Unavailable

2

Gasket, Plug

3084920

Unavailable

3

SPRING,TENSIONER

3086839

Unavailable

4

TENSIONER,ASM (Incl. 1-3)

3086813

Unavailable

5

NUT(10)

3084912

$3.97

5

NUT(10)

3084912

$3.97

5

NUT(10)

3084912

$3.97

6

SCREW, ADJ.

3084911

$9.52

6

SCREW, ADJ.

3084911

$9.52

6

SCREW, ADJ.

3084911

$9.52

7

ROCKERARM ASM,INTAKE * (Incl. 5,6)

3084910

$125.46

7

ROCKERARM ASM,INTAKE * (Incl. 5,6)

3084910

$125.46

8

SHAFT,ROCKER

3084909

$52.60

9

ROCKERARM ASM,EXHAUST * (Incl. 5,6)

3084913

$166.24

10

COLLET,VALVE

3084908

$4.84

10

COLLET,VALVE

3084908

$4.84

11

RETAINER,VAVLE SPRING

3086893

Unavailable

11

RETAINER,VAVLE SPRING

3086893

Unavailable

12

SPRING,VALVE Substituted by 3086892

3084906

$28.32

12

SPRING,VALVE Substituted by 3086892

3084906

$28.32

13

CAMSHAFT * (Incl. 14-17)

3086212

$379.99

14

DOWEL-PIN

3086838

$7.14

15

LEVER, RELEASE

3085348

Unavailable

16

SPRING,RETURN

3085076

Unavailable

17

PIN,DOWEL

3084899

$7.14

18

SPROCKET 2

3084914

Unavailable

19

GUIDE,CHAIN

3084916

Unavailable

20

BOLT&WASHER ASM.

3081657

$4.76

21

CHAIN, TIMING *

3084915

$101.17

22

BOLT,PIVOT,LEVER

3084924

Unavailable

23

LEVER

3084917

Unavailable

24

VALVE,INTAKE

3085349

$68.79

25

VALVE, EXHAUST

3085412

$93.08

26

GASKET,TENSIONER

3084922

Unavailable

27

BOLT, FLANGE

3084874

Unavailable
