Sea-doo Speedster 200 Twin 4-TEC SCIC, Edition 1, 2006 Inlet Clearance System (ICS) Diagram

#

Description
Price

1

Steering Cable Lock This part replaces 277000784.

277001729

$13.22

2

LH Weedless Cable, Port Side

204200113

Unavailable

3

RH Weedless Cable, Starboard

204200114

Unavailable

4

HALF RING - Call your local BRP dealership

204200009

Unavailable

5

THRU HULL SEAL - Call your local BRP dealership

204200118

Unavailable

6

Loctite 243, 10 ml

293800060

$21.49

7

Pivot Socket Screw M5 x 0.8

204100138

Unavailable

8

FLAT WASHER 5 MM - Call your local BRP dealership

234052100

$1.99

9

Jet Pump Bearing Grease, 110 G

293550032

Unavailable

10

Joint

204200006

Unavailable

11

Hex. Jam Nut

212100006

Unavailable

12

Flat Washer

213200017

Unavailable

13

Loctite 243, 10 ml

293800060

$21.49

14

Boot, Large

277000473

Unavailable

15

Boot, Small

277000466

Unavailable

16

Hex. Nut

212100005

$1.35

17

Loctite 243, 10 ml

293800060

$21.49

18

BALL JOINT - Call your local BRP dealership

277000153

Unavailable

19

Hex. Screw M6 X 70

207067060

$5.61

20

Flat Washer M6, Stainless

234062600

$0.77

21

NYLON SPACER - Call your local BRP dealership

204200112

Unavailable

22

Hex. Elastic Stop Nut M6

232561600

$1.15

23

Weedless Support Ass'y

204471003

Unavailable

24

Pivot-arm Ass'y

204471006

Unavailable

25

Hex. Screw M6 X 16

207161660

$1.59

26

Stainless Flat Washer M6

234061600

$0.33

27

SPACER 6.7 MM - Call your local BRP dealership

277000584

Unavailable

28

Loctite 243, 10 ml

293800060

$21.49

29

Hex. Screw M6 X 30

207163060

$1.48

30

Stainless Flat Washer M6

234061600

$0.33

31

Loctite 243, 10 ml

293800060

$21.49

32

V.T.S. HOUSING ASSY - Call your local BRP dealership | Includes 27 to 36

278001606

Unavailable

33

Male Terminal | XT Models

278000222

$3.19

34

Female Terminal

278000223

$3.19

35

FEMALE CONNECTOR, 6 CIRCUITS - Call your local BRP dealership

278000156

Unavailable

36

Male Connector, 2 Circuits

278000220

$15.49

37

Wire Seal

278000218

$4.39

38

Insulated Sheath

278001008

$3.28

39

Insulated Sheath

278001007

$3.58

40

Female Terminal | DS 650 X

278001009

$3.19

41

Male Terminal

278000230

$4.39

42

Windshield Motor

278002579

$234.99

43

Insulation Sheath

278000231

$5.08

44

Male Terminal

278000230

$4.39

45

Hex. Elastic Stop Nut M6

232561600

$1.15

46

Worm Screw

278000428

$14.30

47

Sliding Block Ass’y

278001698

$43.99

48

Synthetic Grease, 400 G

293550010

Unavailable

49

GASKET - Call your local BRP dealership

293200027

Unavailable

50

V.T.S. COVER - Call your local BRP dealership

278000595

Unavailable

51

GROMMET - Call your local BRP dealership

293720015

Unavailable

52

ABS SPACER - Call your local BRP dealership

204470857

Unavailable

53

SPECIAL NUT M27 - Call your local BRP dealership

211100020

Unavailable

54

Hex. Screw M6 X 40

207164060

$3.38

55

Jet Pump Bearing Grease, 110 G

293550032

Unavailable

56

Flat Washer M6, Stainless

234062600

$0.77

57

Hex. Elastic Stop Nut M6

232561600

$1.15

58

Hex. Screw M8 X 30

207183060

$1.58

59

Flat Washer M8, Stainless

234080600

$1.48

60

Hex. Elastic Nut M8

232581600

$1.48

61

Pop Rivet 3/16"

293150039

$1.49
