Partiron

Sea-doo SPARK ACE 900 (2up), 2014 Reverse _31S1402 Diagram

#

Description
Price

2

Socket Head Screw M6 X 16, Scotch Grip

205561660

$1.57

4

Hex. Screw M6 X 35

207063560

$2.12

5

Hex. Screw M8 X 40

207084060

$2.12

7

Hex. Screw M8 X 25, Scotch Grip

207382560

$2.27

8

Elastic Stop Nut M6, Brass

232561200

$4.03

9

Hex. Elastic Nut M8 Brass

232581200

$1.48

10

Stainless Flat Washer M6

234061600

$0.28

11

Flat Washer M6, Stainless

234062600

$0.73

12

Flat Washer M8, Stainless

234080600

$1.43

13

Flat Washer 8 mm, Stainless

234082600

$2.27

14

Not Available As Spare Parts

XXX

Unavailable

17

Nozzle

267000705

$69.37

18

Socket Head Screw M8 X 13

268000141

$7.85

19

LH Reverse Support

268000163

$24.60

20

RH Reverse Support

268000166

$28.33

21

Reverse Gate Ass'y | Trim Ramp Kit 295501170

268000169

$145.49

24

Trimming Ring

268000179

$85.79

25

NUT - Call your local BRP dealership

268000185

Unavailable

26

Boot

268000186

$4.12

27

Reverse Rod

268000187

$26.09

28

Not Available As Spare Parts

XXX

Unavailable

29

Plain Bearing

268000202

$3.79

30

Roller Bushing Kit | Includes 240 to 240b

295501160

$3.79

32

Shoulder Pin

268000309

$17.13

33

Gasket

268000208

$14.37

34

Actuator Support

268000210

$17.13

35

Inner Boot This part replaces 268000345.

268000211

$9.34

36

Spacer

271001020

$10.60

37

Spacer

271001039

$13.52

38

Actuator Ass'y | Ref Service Bulletin 2015-8

278002996

Unavailable

38

Actuator | Includes 10 to 10j

278003606

$738.78

38

IBR Conversion Kit | Ref Service Bulletin 2015-8

295501184

$92.51

87

O-Ring

293300068

$6.07

90

Hexalob Screw M4 X 10

250000565

$2.00

91

Oetiker Clamp

293650042

$1.61

92

Crimp Clamp

293650099

$4.07

95

Venturi Bushing

293900007

$4.25

96

Plastic Bushing

293900010

$8.21

97

Oetiker Gear Clamp, 36.5-706R

509000529

$9.42
