Suzuki SP500 (1983) ELECTRICAL Diagram

#

Description
Price

1

NO DESCRIPTION AVAILABLE This part replaces 33410-37410.

33410-23011

Unavailable

2

SCREW This part replaces 02112-06208.

02112-06207

$1.78

3

LOCK WASHER This part replaces 08321-21068.

08321-01067

$2.13

4

CAP, SPARK PLUG

33510-45010

$24.99

5

SEAL, SPARK PLUG This part replaces 33541-32410.

33541-38210

$4.68

6

SEAL,HIGH TENSION CORD (SIDE) This part replaces 33542-98000.

33542-38B00

$4.34

7

CDI UNIT ASSY This part replaces 32900-37420.

32900-37410

Unavailable

8

SCREW This part replaces 02112-06168.

02112-06167

$1.49

9

LOCK WASHER This part replaces 08321-21068.

08321-01067

$2.13

10

WASHER (6.5X18X1.6) This part replaces 09160-06039.

09160-06109

$1.49

11

REGULATOR ASSY This part replaces 32500-37410.

32500-35400

Unavailable

12

SCREW This part replaces 02112-06168.

02112-06167

$1.49

13

LOCK WASHER This part replaces 08321-21068.

08321-01067

$2.13

14

WASHER This part replaces 08322-21068.

08322-01067

$2.13
