Suzuki SP500 (1982) RIGHT HANDLE SWITCH (MODEL Z) Diagram

GRIP,THROTTLE This part replaces 57110-37200.

57110-37201

$26.30

CASE ASSY, THROTTLE | Includes Item(s) 3

57100-37400

$94.55

SCREW This part replaces 02112-05208.

02112-05207

$1.97

LEVER ASSY, BRAKE | Includes Item(s) 5 - 11 This part replaces 57300-38210.

57300-05210

Unavailable

LEVER, BRAKE

57420-26400

Unavailable

BOLT This part replaces 57431-11011.

57431-11013

$6.31

.NUT This part replaces 08319-21068.

08319-2106A

$1.91

SCREW This part replaces 02112-06208.

02112-06207

$1.78

ADJUSTER, CABLE

57441-11010

$5.62

NUT

57442-11010

$2.79

SWITCH ASSY, STOP This part replaces 57470-10300.

57460-10400

$37.53

SWITCH ASSY, ENGINE STOP This part replaces 37830-37410.

37830-38200

Unavailable

COVER, CLUTCH LEVER This part replaces 57341-40001.

57341-40003

$5.56

BAND (L:120) This part replaces 09407-12403.

09407-12402

$3.04
