Polaris SLINGSHOT S/LE (R02) - T22AASGD/AASHD/AATGD/AATHD/AALHD/AALGD ENGINE, COOLING - T22AASGDAA/BA/SHDAA/BA/TGDAA/AB/BA/BB/THDAA/AB/BA/BB/LHDAR/BR/CR/LGDAR/BR/CR (500195C) Diagram

#

Description
Price

1

SEAL-STEERING RACK

5814706

$23.81

2

SHROUD-REAR RADIATOR

5454505

$52.60

3

SCREW-TXBH-M6x1.0x15 8.8 ZB3 SH

7520011

$2.38

3

SCREW-TXBH-M6x1.0x15 8.8 ZB3 SH

7520011

$2.38

3

SCREW-TXBH-M6x1.0x15 8.8 ZB3 SH

7520011

$2.38

3

SCREW-TXBH-M6x1.0x15 8.8 ZB3 SH

7520011

$2.38

4

RIVET-TUFLOK,.315-.325X.787

7661855

$1.19

4

RIVET-TUFLOK,.315-.325X.787

7661855

$1.19

4

RIVET-TUFLOK,.315-.325X.787

7661855

$1.19

4

RIVET-TUFLOK,.315-.325X.787

7661855

$1.19

4

RIVET-TUFLOK,.315-.325X.787

7661855

$1.19

5

ASM-FAN SHROUD,NOBYPASS

5458870

$169.43

6

CLIP-PUSH IN, 0.50

7081968

$6.35

6

CLIP-PUSH IN, 0.50

7081968

$6.35

7

GROMMET-ARB,24MM

5417967

$3.17

8

MOTOR-FAN,CLG,SLINGER

1241449

Unavailable

8

MOTOR-FAN,CLG,SLINGER

1241449

Unavailable

9

SCR-TXTH-M5X0.8X25 T20 ZPB

7520280

$3.99

9

SCR-TXTH-M5X0.8X25 T20 ZPB

7520280

$3.99

10

BUSHING-MOUNT,LOWER RADIATOR

5410584

$5.56

11

CORE-RADIATOR,17FPI (INCL. DRAIN VALVE)

1241386

Unavailable

11

VALVE-PLASTIC RAD/COOLER DRAIN

7052410

$28.32

12

BRACKET-RETRAINT,RADIATOR

5263541-329

$24.99

13

SCREW-HXFL-M6X1.0X16 8.8 ZPB

7518591

$3.79

13

SCREW-HXFL-M6X1.0X16 8.8 ZPB

7518591

$3.79

14

DUCT,INLET

5455737

$91.97

15

CLAMP-CTB28

7082287

$3.97

16

HOSE-SURGE TANK

5416815

$94.99

17

HOSE-OVERFLOW

5416063

$43.56

18

CLAMP, HOSE, SPRING

7082286

$7.14

19

CLIP FIR-TREE,DIA6-33MM

7081496

$4.76

19

CLIP FIR-TREE,DIA6-33MM

7081496

$4.76

20

ASM., VENT HOSE

5417506

$60.70

21

CABLE-TIE,DIA6-38MM,DUAL-LOOP

7081916

$4.84

22

TANK, SURGE [TO 01/01/2024

5455083

Unavailable

22

TANK-SURGE,YS [FROM 01/01/2024]

5465188

Unavailable

23

SCREW-HXFL-M6X1.0X20 8.8 ZY3

7518576

$3.17

23

SCREW-HXFL-M6X1.0X20 8.8 ZY3

7518576

$3.17

24

CAP, SURGE TANK

5439573

$39.99

25

SHIELD-COOLANT TANK

5416928

$36.41

26

CLAMP-CTB58

7082270

$7.14

27

HOSE-ENGINE INLET

5416069

$48.56

28

CLAMP-CTB42

7082625

$7.14

28

CLAMP-CTB42

7082625

$7.14

28

CLAMP-CTB42

7082625

$7.14

28

CLAMP-CTB42

7082625

$7.14

28

CLAMP-CTB42

7082625

$7.14

28

CLAMP-CTB42

7082625

$7.14

29

BRACKET-COOLANT TUBE

5453830

$8.08

30

BRACKET-COOLANT TUBE

5263829-329

$15.99

31

ASM., BRACKET COOLANT LINE

5265524-329

$28.32

33

SCR-TXTH-M6X1.0X50, 8.8, ZPB

7519001

$3.97

34

HOSE,RADIATOR OUTLET

5416485

$48.56

35

HOSE-RADIATOR,INLET

5416066

$52.60

36

TUBE-COOLANT,UPPR

5345610

$40.46

37

TUBE-COOLANT,LOWR

5345611

$48.56

38

CLAMP-HOSE

7080807

$9.52

39

HOSE-ENGINE OUTLET

5417090

$60.70

40

CLAMP-CTB51,GRAY

7082530

$6.35

41

CLIP-U SPEED NUT

7081305

$1.98

41

CLIP-U SPEED NUT

7081305

$1.98

42

CLIP-DART,TRW PC47561

7670142

$1.19

42

CLIP-DART,TRW PC47561

7670142

$1.19
