Polaris SLINGSHOT R GRAND TOURING (R01) - T25AAGGB/HB CHASSIS, MAIN, AND REAR ASM. - T25AAGGB/HB (500402C) Diagram

#

Description

Price

1

WELD-MAINFRAME,CHASSIS,CRSBLK

1028410-266

$7,584.99

2

WELD-SUBFRAME,REAR [INCLUDES 3]

1028139

$999.99

3

NUT-RIVNUT,M6X1.0,ROUND,OPEN

7548138

Unavailable

4

WELD-TUBE,REAR BRACE

1021668

$125.46

5

HOOP-ROLL,LH,FLAT BLACK

5144613-463

$669.99

6

HOOP-ROLL,RH,FLAT BLACK

5144614-463

$669.99

7

SCR-M8X1.25X55,HX/FL-Y

7517281

$8.99

8

NUT- M8X1.25, FLG, NYLOC-OLIVE D

7547332

$3.97

9

SCR-HXFL-M12X1.75X70 10.9,ZPC

7521334-70

$4.76

10

SCR-HXFL-M10X1.5X90 10.9 ZOD

7519790

$2.62

11

NUT-HXFL-M10X1.50 10 ZPC

7547017

$5.56

12

CLIP-DART,TRW PC47561

7670142

$1.19
