Honda SL90A MOTORCYCLE, JPN, VIN# SL90-100001 FRONT WHEEL Diagram

#

Description
Price

NI

SHOE SET, BRAKE (JB) This part replaces 06450-GAG-003.

06450-178-932

$24.89

NI

SHOE SET, BRAKE (JB) This part replaces 06450-001-405.

06450-178-932

$24.89

NI

SHOE SET, BRAKE (JB)

06450-178-932

$24.89

NI

SHOE SET, BRAKE (JB) This part replaces 451A0-001-670.

06450-178-932

$24.89

1

AXLE, FR. WHEEL

44301-074-000

Unavailable

2

COLLAR, FR. WHEEL SIDE (NOT AVAILABLE)

44311-074-000

Unavailable

3

HUB, FR. WHEEL This part replaces 44601-028-000.

44601-397-000

Unavailable

3

HUB, FR. WHEEL This part replaces 44601-107-770.

44601-397-000

Unavailable

3

HUB, FR. WHEEL

44601-397-000

Unavailable

4

COLLAR, FR. AXLE DISTANCE

44620-030-000

Unavailable

5

RIM, FR. WHEEL (1.40X19) (DAIDO) This part replaces 44701-074-003.

44701-364-711

Unavailable

5

RIM, FR. WHEEL (1.40X19) (DAIDO)

44701-364-711

Unavailable

6

TIRE, FR. (2.75-19) (NITTO) (NOT AVAILABLE) This part replaces 44711-074-006.

44711-074-016

Unavailable

6

TIRE, FR. (2.75-19) (NITTO) (NOT AVAILABLE)

44711-074-016

Unavailable

7

TUBE, TIRE (2.50-19) (IRC) This part replaces 0Y400-07410.

44712-167-005

Unavailable

7

TUBE, TIRE (2.50-19) (IRC) This part replaces 08400-07410.

44712-167-005

Unavailable

7

TUBE, TIRE (2.50-19) (IRC) This part replaces 44712-074-006.

44712-167-005

Unavailable

7

TUBE, TIRE (2.50-19) (IRC) This part replaces 44712-167-003.

44712-167-005

Unavailable

7

TUBE, TIRE (2.50-19) (IRC)

44712-167-005

Unavailable

8

FLAP, TIRE (NOT AVAILABLE)

44713-028-000

Unavailable

9

GEAR, SPEEDOMETER

44804-028-000

Unavailable

9

GEAR, SPEEDOMETER This part replaces 44806-028-000.

44804-028-000

Unavailable

10

CABLE, SPEEDOMETER

44830-074-000

Unavailable

12

PANEL, FR. BRAKE This part replaces 45010-102-000.

45010-350-000

Unavailable

12

PANEL, FR. BRAKE

45010-350-000

Unavailable

12

PANEL, FR. BRAKE This part replaces 45100-028-000.

45010-350-000

Unavailable

13

SHOE, BRAKE (SEE KIT P/N--END OF BLOCK) (N/A: USE P/N 451A0-001-670)

45120-001-010

Unavailable

14

CAM, FR. BRAKE (NOT AVAILABLE)

45131-041-000

Unavailable

14

CAM, FR. BRAKE (NOT AVAILABLE) This part replaces 45131-041-010.

45131-041-000

Unavailable

15

SPRING, BRAKE SHOE

45133-028-000

$2.03

16

ARM, FR. BRAKE (NOT AVAILABLE)

45410-028-000

Unavailable

17

NUT, FR. BRAKE ARM SETTING

45436-001-000

$1.80

18

SPRING, FR. BRAKE ARM

45437-001-000

$3.50

19

JOINT A, BRAKE ARM This part replaces 45461-001-000.

95015-31001

$1.53

19

JOINT A, BRAKE ARM This part replaces 95015-31000.

95015-31001

$1.53

19

JOINT A, BRAKE ARM

95015-31001

$1.53

20

NUT A, BRAKE ROD ADJUSTING This part replaces 45462-028-000.

95015-41000

$1.49

20

NUT A, BRAKE ROD ADJUSTING

95015-41000

$1.49

21

NUT, AXLE (NOT AVAILABLE)

90305-028-000

Unavailable

22

WASHER, RR. BRAKE ARM

90525-001-000

$1.95

23

OIL SEAL (21X37X7) (ARAI) This part replaces 90755-229-000.

90755-229-003

$5.05

23

OIL SEAL (21X37X7) (ARAI)

90755-229-003

$5.05

23

OIL SEAL (21X37X7) (ARAI) This part replaces 90755-229-005.

90755-229-003

$5.05

24

OIL SEAL (47X58X7) This part replaces 91251-030-000.

91251-030-003

Unavailable

24

OIL SEAL (47X58X7)

91251-030-003

Unavailable

25

BOLT, HEX. (6X25) This part replaces 92000-06025.

92101-06025-0A

$1.62

25

BOLT, HEX. (6X25)

92101-06025-0A

$1.62

26

BEARING, RADIAL BALL (6301U) This part replaces 96100-63010.

96140-63010-10

$14.84

26

BEARING, RADIAL BALL (6301U) This part replaces 96140-63010.

96140-63010-10

$14.84

26

BEARING, RADIAL BALL (6301U)

96140-63010-10

$14.84

27

SPOKE A (11X185.5)

97281-31211-10

$3.26

28

SPOKE A (11X185)

97408-31210-10

$3.26
