Honda SL175A MOTORCYCLE, JPN, VIN# SL175-1000001 FRONT WHEEL Diagram

SHOE KIT, BRAKE

06430-354-405

Unavailable

SHOE KIT, BRAKE This part replaces 06430-354-670.

06430-354-405

Unavailable

SHOE KIT, BRAKE This part replaces 431A2-354-670.

06430-354-405

Unavailable

AXLE, FR. WHEEL | Use up to Frame SN 1021227

44301-240-000

Unavailable

AXLE, FR. WHEEL | Use from Frame SN 1021228

44301-304-971

Unavailable

COLLAR, FR. WHEEL SIDE (NOT AVAILABLE) This part replaces 44311-240-000.

44311-286-000

Unavailable

HUB, FR. WHEEL (NOT AVAILABLE) This part replaces 44601-230-010.

44601-230-020

Unavailable

HUB, FR. WHEEL (NOT AVAILABLE)

44601-230-020

Unavailable

SPOKE A, FR.

44602-313-003

Unavailable

SPOKE B

44603-313-003

Unavailable

COLLAR, FR. AXLE DISTANCE

44620-230-000

$9.90

RIM, FR. WHEEL (19) (DAIDO) (NOT AVAILABLE)

44701-290-003

Unavailable

TIRE, FR. (3.00-19) (4PR) (INOUE) (NOT AVAILABLE)

44711-313-003

Unavailable

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 08400-31310.

44712-110-003

Unavailable

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 08400-41310.

44712-110-003

Unavailable

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-290-000.

44712-110-003

Unavailable

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-310-004.

44712-110-003

Unavailable

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-312-003.

44712-110-003

Unavailable

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-401-681.

44712-110-003

Unavailable

TUBE, TIRE (19) (BS) (NOT AVAILABLE) This part replaces 44712-413-009.

44712-110-003

Unavailable

FLAP, TIRE (100/90-19) (57S) (BS)

44713-MR1-671

$7.32

FLAP, TIRE (BS) This part replaces 44713-290-000.

44713-MR1-671

$7.32

GEAR, SPEEDOMETER (NOT AVAILABLE)

44806-313-010

Unavailable

PANEL, FR. BRAKE (NOT AVAILABLE)

45100-313-020

Unavailable

*06430-354-405 This part replaces 43120-354-670.

43120-354-405

Unavailable

*06430-354-405 This part replaces 45120-240-000.

43120-354-405

Unavailable

*06430-354-405 This part replaces 45120-240-010.

43120-354-405

Unavailable

CAM, BRAKE (NOT AVAILABLE) | Use up to Frame SN 1015359

45131-230-020

Unavailable

CAM, FR. BRAKE | Use from Frame SN 1015360

45131-313-000

Unavailable

SPRING, BRAKE SHOE

45133-240-000

Unavailable

DUST SEAL, BRAKE CAM

45134-250-000

$2.92

ARM, FR. BRAKE

45410-230-030

Unavailable

ARM, FR. BRAKE STOPPER This part replaces 45431-235-000.

45431-336-000

Unavailable

ARM, FR. BRAKE STOPPER

45431-336-000

Unavailable

SPRING, FR. BRAKE ARM RETURN

45435-250-000

$4.61

JOINT A, BRAKE ARM This part replaces 45461-001-000.

95015-31001

$1.53

JOINT A, BRAKE ARM This part replaces 95015-31000.

95015-31001

$1.53

JOINT A, BRAKE ARM

95015-31001

$1.53

NUT A, BRAKE ROD ADJUSTING This part replaces 45462-028-000.

95015-41000

$1.49

NUT A, BRAKE ROD ADJUSTING

95015-41000

$1.49

BOLT, HEX. (8X28) This part replaces 90126-292-000.

93201-08028-0A

$1.75

BOLT, HEX. (8X28) This part replaces 93200-08028.

93201-08028-0A

$1.75

BOLT, HEX. (8X28) This part replaces 93200-08028-0A.

93201-08028-0A

$1.75

BOLT, HEX. (8X28)

93201-08028-0A

$1.75

WASHER A, HANDLE HOLDER SETTING

90524-030-000

$1.49

WASHER B, TONGUED (8.2MM) (NOT AVAILABLE)

90533-286-000

Unavailable

WASHER (15.2X25)

90557-230-000

$2.39

OIL SEAL (54X66X7) This part replaces 91251-230-000.

91251-230-003

$12.60

OIL SEAL (54X66X7)

91251-230-003

$12.60

OIL SEAL (26X42X7)

91252-230-003

$10.56

BOLT, HEX. (6X28) This part replaces 92000-06028.

92101-06028-0A

$1.49

BOLT, HEX. (6X28)

92101-06028-0A

$1.49

BOLT, HEX. (8X28) This part replaces 92000-08028-0A.

92101-08028-0A

$1.80

BOLT, HEX. (8X28)

92101-08028-0A

$1.80

SCREW, FLAT (5X20)

93600-05020-0A

$1.49

SCREW, FLAT (5X20) This part replaces 93617-05020-0A.

93600-05020-0A

$1.49

NUT, HEX. (6MM) This part replaces 90310-KA3-711.

94001-06200-0S

$1.49

NUT, HEX. (6MM) This part replaces 94000-06000-0S.

94001-06200-0S

$1.49

NUT, HEX. (6MM) This part replaces 94001-06000.

94001-06200-0S

$1.49

NUT, HEX. (6MM) This part replaces 94001-06000-0S.

94001-06200-0S

$1.49

NUT, HEX. (6MM) This part replaces 94001-06008-0S.

94001-06200-0S

$1.49

NUT, HEX. (6MM)

94001-06200-0S

$1.49

NUT, HEX. (6MM) This part replaces 94030-06000.

94001-06200-0S

$1.49

NUT, HEX. (14MM) | Use up to Frame SN 1021227

94001-14020-0S

Unavailable

NUT, CASTLE (14MM) (NOT AVAILABLE) | Use from Frame SN 1021228

94011-14020-0S

Unavailable

WASHER, PLAIN (6MM) This part replaces 94101-06000.

94101-06800

$1.49

WASHER, PLAIN (6MM) This part replaces 94101-06080.

94101-06800

$1.49

WASHER, PLAIN (6MM)

94101-06800

$1.49

PIN, COTTER (2.0X22) This part replaces 94201-20180.

94201-29220

$1.49

PIN, COTTER (2.0X22) This part replaces 94201-20200.

94201-29220

$1.49

PIN, COTTER (2.0X22)

94201-20220

$1.49

PIN, COTTER (2.0X35) This part replaces 94201-20250.

94201-20350

$1.49

PIN, COTTER (2.0X35) This part replaces 94201-20280.

94201-20350

$1.49

PIN, COTTER (2.0X35) This part replaces 94201-20320.

94201-20350

$1.49

PIN, COTTER (2.0X35)

94201-20350

$1.49

PIN, COTTER (2.0X22)

94201-29220

$1.49

PIN, COTTER (3.0X45) | Use from Frame SN 1021228 This part replaces 94201-30250.

94201-30450

$1.49

PIN, COTTER (3.0X45) | Use from Frame SN 1021228 This part replaces 94201-30280.

94201-30450

$1.49

PIN, COTTER (3.0X45) | Use from Frame SN 1021228 This part replaces 94201-30300.

94201-30450

$1.49

PIN, COTTER (3.0X45) | Use from Frame SN 1021228 This part replaces 94201-30400.

94201-30450

$1.49

PIN, COTTER (3.0X45) | Use from Frame SN 1021228

94201-30450

$1.49

BEARING, RADIAL BALL (6302Z) (SOURCE: VINTAGE PARTS INC.)

96120-63020

Unavailable
