Honda SL125K2A MOTORCYCLE, JPN, VIN# SL125S-1200001 TO SL125S-1216831 FRONT WHEEL Diagram

#

Description
Price

NI

SHOE SET, BRAKE (JB) This part replaces 06450-GAG-003.

06450-178-932

$24.89

NI

SHOE SET, BRAKE (JB) This part replaces 06450-001-405.

06450-178-932

$24.89

NI

SHOE SET, BRAKE (JB)

06450-178-932

$24.89

NI

SHOE SET, BRAKE (JB) This part replaces 451A0-001-670.

06450-178-932

$24.89

1

AXLE, FR. WHEEL This part replaces 44301-110-000.

44301-KF9-900

Unavailable

2

COLLAR, FR. WHEEL SIDE

44311-229-000

$6.58

3

HUB, FR. WHEEL This part replaces 44601-107-770.

44601-397-000

Unavailable

3

HUB, FR. WHEEL

44601-397-000

Unavailable

4

COLLAR, FR. AXLE DISTANCE

44620-030-000

Unavailable

5

RIM, FR. WHEEL (1.40X21) (DAIDO) (NOT AVAILABLE) This part replaces 44701-331-671.

44701-382-791

Unavailable

5

RIM, FR. WHEEL (1.40X21) (DAIDO) (NOT AVAILABLE)

44701-382-791

Unavailable

6

TIRE, FR. (2.75-21) (NITTO) (NOT AVAILABLE)

44711-362-006

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE) This part replaces 0Y400-33100.

44712-446-631

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE) This part replaces 08400-33100.

44712-446-631

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE) This part replaces 08400-34010.

44712-446-631

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE) This part replaces 44712-KB1-911.

44712-446-631

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE) This part replaces 44712-MC4-005.

44712-446-631

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE) This part replaces 44712-331-671.

44712-446-631

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE) This part replaces 44712-340-003.

44712-446-631

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE) This part replaces 44712-340-006.

44712-446-631

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE) This part replaces 44712-400-004.

44712-446-631

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE) This part replaces 44712-437-971.

44712-446-631

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE) This part replaces 44712-446-003.

44712-446-631

Unavailable

7

TUBE, TIRE (2.75/3.00-21) (INOUE)

44712-446-631

Unavailable

8

FLAP, TIRE (21) (NITTO) (NOT AVAILABLE)

44713-331-671

Unavailable

9

GEAR, SPEEDOMETER (NOT AVAILABLE)

44804-331-600

Unavailable

9

GEAR, SPEEDOMETER (NOT AVAILABLE) This part replaces 44806-331-671.

44804-331-600

Unavailable

10

PANEL, FR. BRAKE

45010-331-600

Unavailable

10

PANEL, FR. BRAKE This part replaces 45010-331-671.

45010-331-600

Unavailable

11

SHOE, BRAKE (SEE KIT P/N--END OF BLOCK) (N/A: USE P/N 451A0-001-670)

45120-001-010

Unavailable

12

CAM, FR. BRAKE (NOT AVAILABLE)

45131-030-000

Unavailable

13

SPRING, BRAKE SHOE

45133-028-000

$2.03

14

ARM, FR. BRAKE (NOT AVAILABLE)

45410-028-000

Unavailable

15

NUT, FR. BRAKE ARM SETTING

45436-001-000

$1.80

16

SPRING, FR. BRAKE ARM

45437-001-000

$3.50

17

JOINT A, BRAKE ARM This part replaces 45461-001-000.

95015-31001

$1.53

17

JOINT A, BRAKE ARM This part replaces 95015-31000.

95015-31001

$1.53

17

JOINT A, BRAKE ARM

95015-31001

$1.53

18

NUT A, BRAKE ROD ADJUSTING This part replaces 45462-028-000.

95015-41000

$1.49

18

NUT A, BRAKE ROD ADJUSTING

95015-41000

$1.49

19

NUT, AXLE (12MM) This part replaces 90305-051-000.

90305-169-000

$6.28

19

NUT, AXLE (12MM)

90305-169-000

$6.28

20

WASHER, RR. BRAKE ARM

90525-001-000

$1.95

21

OIL SEAL (21X37X7) (ARAI) This part replaces 90755-229-000.

90755-229-003

$5.05

21

OIL SEAL (21X37X7) (ARAI)

90755-229-003

$5.05

21

OIL SEAL (21X37X7) (ARAI) This part replaces 90755-229-005.

90755-229-003

$5.05

22

OIL SEAL (47X58X7) This part replaces 91251-030-000.

91251-030-003

Unavailable

22

OIL SEAL (47X58X7)

91251-030-003

Unavailable

23

BOLT, HEX. (6X25) This part replaces 92000-06025.

92101-06025-0A

$1.62

23

BOLT, HEX. (6X25)

92101-06025-0A

$1.62

24

PIN, COTTER (3.0X45) This part replaces 94201-30250.

94201-30450

$1.49

24

PIN, COTTER (3.0X45) This part replaces 94201-30300.

94201-30450

$1.49

24

PIN, COTTER (3.0X45) This part replaces 94201-30400.

94201-30450

$1.49

24

PIN, COTTER (3.0X45)

94201-30450

$1.49

25

BEARING, RADIAL BALL (6301U) This part replaces 96140-63010.

96140-63010-10

$14.84

25

BEARING, RADIAL BALL (6301U)

96140-63010-10

$14.84

26

SPOKE A (11X231.5)

97272-31303-10

Unavailable

27

SPOKE A (11X231) (NOT AVAILABLE)

97466-31302-10

Unavailable
