Ski-Doo Skandic Super Wide Track, 1997 10- Electrical System (494) Diagram

#

Description
Price

1

Battery Cover

570022000

Unavailable

2

HEX. SCREW M6 X 12 - Call your local BRP dealership

207161244

Unavailable

3

Flat Washer 6 mm

234061410

$1.36

4

Elastic Stop Nut M6

232561414

$0.55

5

Battery | Includes 4 - 8.

410301100

Unavailable

6

FLAT WASHER - Call your local BRP dealership

391302100

Unavailable

7

Battery Cap

410300800

Unavailable

8

Hex. Screw M6 X 16

207161644

$0.74

9

Hex. Nut M6

232061414

$0.53

10

Overflow Tank | Skandic Wide Track LC.

M281461402

Unavailable

11

TIE RAP 98MM - Call your local BRP dealership

M27010

Unavailable

12

Tube

M39055

Unavailable

13

Steel Strip | Skandic Super Wide Track.

M549888

Unavailable

14

Steel Strip | Skandic Wide Track LC.

M5341035

Unavailable

15

Lock Washer M6, Black

234161471

$0.53

16

Screw M6 x 25 | Skandic Super Wide Track.

M40108

Unavailable

17

Starter Relay | Skandic WT LC.

420992817

Unavailable

18

Washer 5,3 mm

20008

$0.74

19

Lock Washer

M20013

Unavailable

20

Ground Wire | Skandic Wide Track LC.

M5440814

Unavailable

21

Battery Wire | Skandic WT LC.

M5440815

Unavailable

22

Battery Wire | Skandic Wide Track LC.

M5440816

Unavailable

23

Elastic Stop Nut M6

232561414

$0.55

24

Electric Starter | Includes 1 - 18. Skandic WT LC.

410207500

Unavailable

25

Starter Bracket (PTO) | Skandic WT LC.

M539431

Unavailable

26

Starter Bracket (MAG) | Skandic WT LC.

M539432

Unavailable

27

Socket Head Screw M8 X 20

205082044

$1.15

28

Hex. Screw M8 X 20

207182044

$0.74

29

Lock Washer 8 mm

234181401

$0.92

30

Hex. Screw M8 x 16

207181644

$1.15

31

Flat Washer M5

234051410

$0.53

32

Elastic Stop Nut M5

232551414

$0.87

33

Ring Gear (86 Theet) | Formula Deluxe 380 F.

414807500

Unavailable

34

Screw

M40322

Unavailable

35

VOLTAGE REGULATOR - Call your local BRP dealership | Skandic 500F. Skandic 500F (SWT).

515163900

Unavailable

36

Hex. Screw M6 X 20 | XT Models

207162044

$0.76

37

Flat Washer 6 mm

234062410

$0.77
