Yamaha SJ650R (SUPER JET) 1993 AIR FILTER Diagram

#

Description
Price

1

MANIFOLD 1

6M6-13641-00-94

Unavailable

2

GASKET

6M6-13566-A2-00

Unavailable

3

MANIFOLD,INTAKE

6M6-13555-01-94

Unavailable

4

. PIPE, JOINT 4

652-24461-00-00

$5.31

5

BOLT, STUD

90116-08M14-00

$5.07

6

NUT (661)

95380-08600-00

$6.14

7

.. WASHER, PLATE

92990-08600-00

$2.17

8

GASKET

6M6-13563-A1-00

Unavailable

9

PLATE

6M6-14527-02-94

Unavailable

10

GASKET, MANIFOLD

6M6-13556-A1-00

$5.91

11

HOSE (L400)

90445-10M43-00

$5.96

12

CLAMP

90465-10098-00

$1.68

13

BOLT(3RV)

97014-06035-00

$1.54

14

WASHER, PLAIN (646)

92990-06600-00

$1.84

15

REED VALVE ASSEMBLY

6R7-13610-01-00

Unavailable

16

. REED SET

6R7-W0004-00-00

Unavailable

17

BOLT(7U8)

97080-06020-00

$3.63

18

WASHER, PLAIN (646)

92990-06600-00

$1.84

19

GASKET, VALVE SEAT

6M6-13621-A1-00

Unavailable

20

BOLT, WITH WASHER

90119-05M02-00

$3.46

21

COVER, CARB.

99999-02651-00

Unavailable

22

COVER, CARBURETOR 2

6M6-14284-00-8P

Unavailable

23

ELEMENT, AIR CLEANER

6M6-14451-00-00

Unavailable

24

SCREW, PAN HEAD(6B0)

97885-05016-00

$4.09

25

WASHER, PLAIN (646)

92990-05600-00

Unavailable

26

GASKET, AIR COOLER COVER 1

6M6-13674-A1-00

$4.99

27

PLATE

6R7-14255-00-00

Unavailable

28

EMBLEM

6R7-1441K-00-00

Unavailable

29

NIPPLE, GREASE

61L-5169A-00-00

$7.40

30

PLATE

61L-14243-00-00

Unavailable

31

CAP, GREASE NIPPLE

663-45119-01-00

Unavailable
