Polaris SCRAMBLER 4X4 - W957840 FRONT WHEEL ASSEMBLY Scrambler W957840 (4927252725B006) Diagram

#

Description
Price

1

Cage, Roll

3250028

Unavailable

2

ROLLS

3250010

$24.74

3

SPRING,GARTER

3250032

$17.46

4

SPACER Substituted by 1321814

3250031

$24.99

5

Cam

3250030

$208.16

6

BOLT(10)

7515321

Unavailable

7

DISC, BRAKE

5211325

$76.89

8

SEAL, FR. HUB

3610019

$36.41

9

Plate, Armature

5211148

$28.32

10

CLUTCH ASM,FR.HUB,E/M,HVY. Substituted by 1520281

1520214

$374.99

11

BRG,TAPER.ROLL.CONE

3554506

$31.75

11

BRG,TAPER.ROLL.CONE

3554506

$31.75

12

BRG,TAPER,ROLL CUP

3554507

$31.75

12

BRG,TAPER,ROLL CUP

3554507

$31.75

13

HUB ASM,W/BRG.RACE (Incl. 8, 12, 14)

1520182

Unavailable

14

STUD(10)

7515523

$3.17

15

PLUG,PIPE

7052045

$13.75

16

TIRE,FR(23X7X10)

5410910

Unavailable

17

VALVE-RIM

1525017

$6.46

18

RIM,FRT.,WHITE

1520207-133

Unavailable

19

WASHER(10)

7555903

Unavailable

20

NUT,RH THREAD

7543201

Unavailable

21

RING,RETAINING(10)

7710436

$4.76

22

O RING

5410470

$2.41

23

CAP, HUB

5431368

$24.27

24

NUT-HXFL-3/8-24 B ZTB P-A

7542459

$1.59
