Honda SA50A (97) ELITE 50 SR, MEX, VIN# 3H1AF160-VD800001 FRONT WHEEL Diagram

SHOE SET, BRAKE (ASK)

06430-GY1-922

$18.48

TIRE (3.00-10) (4PR 42J MB35L) (INOUE)

42711-GS7-673

$73.24

TUBE, TIRE (3.00-10) (INOUE)

42712-GN2-623

Unavailable

TUBE, TIRE (3.00-10) (INOUE) This part replaces 42712-GW0-006.

42712-GN2-623

Unavailable

SPRING, BRAKE SHOE

43151-GC4-000

$4.76

AXLE, FR. WHEEL

44301-GN2-000

Unavailable

COLLAR, FR. WHEEL SIDE

44311-GM4-000

Unavailable

COLLAR, FR. DISTANCE

44620-147-000

$8.80

WHEEL SET, FR. *NH138* (SHASTA WHITE)

44650-GS7-305ZE

Unavailable

GEAR, SPEEDOMETER (14T)

44806-GS7-003

$18.68

PANEL SUB, FR. BRAKE *NH138* (SHASTA WHITE)

45010-GY1-315ZA

Unavailable

SEAL, BRAKE CAM

45134-165-890

$1.57

CAM, FR. BRAKE

45141-GC1-010

$10.56

INDICATOR, FR. BRAKE

45145-GN2-000

Unavailable

ARM, FR. BRAKE

45410-GF0-000

Unavailable

SPRING, BRAKE ARM RETURN

45435-GC3-000

$5.90

NUT, U (10MM)

90304-GE8-003

$3.67

OIL SEAL (19X30.5X7) (ARAI)

90754-147-003

$5.31

OIL SEAL (34X42X5) This part replaces 91252-GF0-003.

91252-GF0-004

$6.16

OIL SEAL (34X42X5) This part replaces 91252-GK1-004.

91252-GF0-004

$6.16

OIL SEAL (34X42X5)

91252-GF0-004

$6.16

BOLT, HEX. (5X25)

92101-05025-0A

$1.49

SCREW, PAN (4X6)

93500-04006-0A

$1.49

NUT, HEX. (5MM)

94001-05000-0S

$2.74

JOINT A, BRAKE ARM

95015-31001

$1.53

NUT A, BRAKE ROD ADJUSTING

95015-41000

$1.49

BEARING, RADIAL BALL (6200U)

96140-62000-10

$15.44
