Polaris RZR XP1000 (R02) - Z20NA_99AC/AL/AN/BC/BL/BN/LL/AZ/BZ/AF/AK/BF/BK SUSPENSION, FRONT SHOCK INTERNALS H.LIFT - Z20NAM99AL (702419) Diagram

#

Description
Price

-

SHOCK-FRT,RZRXP,HC,PIGGYBK,LH [INCL ALL]

7044894

$710.70

-

SHOCK-FRT,RZRXP,HC,PIGGYBK,RH [INCL ALL]

7044895

$710.70

1

EXT SHAFTLOOP .625THD 1" BRG

1800600

$195.99

2

RES BODY, 2.0", 5.0L (HARD CLEAR)

1800392

$107.99

3

12.620L SHAFT-CHROME

1800756

$193.63

4

DROOP SPACER W NEG SPRING

1800858

$44.99

5

RING, SNAP 1.750ID

1800159

$5.59

6

BALL, DETENT 3/16"

1800127

$6.39

7

SPRING-COMP .025X.3, 40.5#

1800128

$10.39

8

RING, SNAP 1.0 ID

1800041

$7.27

8

RING, SNAP 1.0 ID

1800041

$7.27

9

O-RING BODY LOOP

1800030

$2.02

9

O-RING BODY LOOP

1800030

$2.02

10

WIPER

1800034

$31.99

11

NUT, CRIMP (CASTLE) 7/16

1800164

$9.59

12

BUMP STOP, MCU, 2.0Dia x 1.75L (ISC 140174-N)

1800859

$77.44

13

BODY, MONOTUBE CO, 2.0 x 14.285L Hard CLEAR

-------

Unavailable

14

BRIDGE, WIDE 2.0 WER ADJUSTER (CLEAR)

1800921

$137.93

15

CAP, WIPER 2.0 PRESS IN (CLEAR ANODIZE)

1800794

$49.99

16

CLICKER KNOB (BLACK)

1800418

$89.03

17

IFP PISTON ASM 1.750 W BLEED

1800739

$44.99

18

ASM. CLICKER STUD

1800758

$29.99

19

ASM. CLICKER PISTON

1800757

$79.99

20

SCREW, HEAD 10/32 BTN

1800357

$3.19

21

SCREW,SET #8-32

1800700

Unavailable

22

SPRING, CENTURY# 11980 DIRT

1800867

$31.99

23

JAMB NUT, 2.0IN ACME (CLEAR)

1800868

$43.99

24

Retaining Ring

1800862

$6.39

25

.0625 X 1.75 ID WIRE RING

1800795

$7.27

26

O-RING 2-226

1800863

$4.79

26

O-RING 2-226

1800863

$4.79

27

O-RING 2-324

1800184

$5.65

28

SPRING RETAINER

5633421

$69.49

29

SPRING NUT 2in ACME (CLEAR)

1800865

$39.99

30

Piston Assembly (2 in 3 PORT HI FLOW)

1800759

$128.87

31

ASM. SEAL HEAD, 2.0, PRESS- IN, STD SEALS

1800869

$47.99

32

ASM. END CAP 2in (CLEAR)

1800755

$49.99

33

O-RING 2-312

1800810

$3.63

33

O-RING 2-312

1800810

$3.63

34

BEARING HFKS8T-10MM

1800809

$59.99

35

SHIM, 5/8 X .015 X 1.55

-------

Unavailable
