Polaris RZR XP 4 1000 (R09) - Z18VFE99AK/AJ/AW/BK/BJ/BW/LW/K99AK/BK/M99AL SUSPENSION, FRONT SHOCK INTERNALS - Z18VFE99AK/AJ/AW/BK/BJ/BW/LW/K99AK/BK (702424) Diagram

#

Description
Price

-

SHOCK-FRT,RZRXP,PIGGYBK,MP,LH [INCL ALL]

7044891

$695.08

-

SHOCK-FRT,RZRXP,PIGGYBK,MP,RH [INCL ALL]

7044892

$695.08

1

EXT SHAFTLOOP .625THD 1" BRG

1800600

$195.99

2

RES BODY, 2.0", 5.0L (HARD CLEAR)

1800392

$107.99

3

SHAFT, .625 CHROME NEEDLE 12.84L .144 BLEED X1

1800662

$114.99

4

DROOP SPACER W NEG SPRING

1800858

$44.99

5

RING, SNAP 1.750ID

1800159

$5.59

6

BALL, DETENT 3/16"

1800127

$6.39

7

SPRING-COMP .025X.3, 40.5#

1800128

$10.39

8

RING, SNAP 1.0 ID

1800041

$7.27

8

RING, SNAP 1.0 ID

1800041

$7.27

9

O-RING BODY LOOP

1800030

$2.02

9

O-RING BODY LOOP

1800030

$2.02

10

WIPER

1800034

$31.99

11

NUT, CRIMP (CASTLE) 7/16

1800164

$9.59

12

BUMP STOP, MCU, 2.0Dia x 1.75L (ISC 140174-N)

1800859

$77.44

13

BODY, MONOTUBE CO, 2.0 x 14.285L Hard CLEAR

1800860

$289.99

14

BRIDGE, WIDE 2.0 WER ADJUSTER (CLEAR)

1800921

$137.93

15

NEEDLE,1PC, PRESS IN

1800861

$59.99

16

CAP, WIPER 2.0 PRESS IN (CLEAR ANODIZE)

1800794

$49.99

17

CLICKER KNOB (BLACK)

1800418

$89.03

18

IFP PISTON ASM 1.750 W BLEED

1800739

$44.99

19

ASM. CLICKER STUD

1800758

$29.99

20

ASM. CLICKER PISTON

1800757

$79.99

21

SCREW, HEAD 10/32 BTN

1800357

$3.19

22

SCREW,SET #8-32

1800700

Unavailable

23

Spring,Century# 11980 DIRT

1800867

$31.99

24

JAMB NUT,2.0in Acme (Clear)

1800868

$43.99

25

Retaining Ring

1800862

$6.39

25

Retaining Ring

1800862

$6.39

26

.0625 X 1.75 ID WIRE RING

1800795

$7.27

27

O-RING 2-226

1800863

$4.79

27

O-RING 2-226

1800863

$4.79

28

O-RING 2-324

1800184

$5.65

29

SPRING RETAINER

5633421

$69.49

30

#8-32 X .500 LOW HEAD SCREW

1800843

$4.79

31

O-RING 2-108

1800864

$4.79

32

SPRING NUT 2in ACME (CLEAR)

1800865

$39.99

33

PISTON ASSEMBLY

1800604

$104.49

34

ASM. END CAP 2in (CLEAR)

1800755

$49.99

34

ASM. END CAP 2in (CLEAR)

1800755

$49.99

35

ASM. SEAL HEAD, 2.0, PRESS- IN, STD SEALS

1800869

$47.99

36

O-RING 2-312

1800810

$3.63

37

BEARING HFKS8T-10MM

1800809

$59.99

37

BEARING HFKS8T-10MM

1800809

$59.99

37

BEARING HFKS8T-10MM

1800809

$59.99

38

5mm ID x 2mm thk. O-RING

-------

Unavailable

39

SHIM, 5/8 X .015 X 1.55

-------

Unavailable
