- RZR XP 1000 (R08) - Z18VDE99AK/AW/AJ/BJ/BK/BW/LW/KAK/BK/MAL/RAL/BL
SUSPENSION, FRONT SHOCK INTERNALS - Z18VDE99AK/AW/AJ/BJ/BK/BW (702420)
Polaris RZR XP 1000 (R08) - Z18VDE99AK/AW/AJ/BJ/BK/BW/LW/KAK/BK/MAL/RAL/BL SUSPENSION, FRONT SHOCK INTERNALS - Z18VDE99AK/AW/AJ/BJ/BK/BW (702420) Diagram
#
-
SHOCK-FRONT,RZRXP,PIGGYBK,LH [INCL ALL]
7044888
$710.70
-
SHOCK-FRONT,RZRXP,PIGGYBK,RH [INCL ALL]
7044889
$710.70
1
EXT SHAFTLOOP .625THD 1" BRG
1800600
$195.99
2
RES BODY, 2.0", 5.0L (HARD CLEAR)
1800392
$107.99
3
SHAFT, .625 CHROME NEEDLE 12.84L .144 BLEED X1
1800662
$114.99
4
DROOP SPACER W NEG SPRING
1800858
$44.99
5
RING, SNAP 1.750ID
1800159
$5.59
6
BALL, DETENT 3/16"
1800127
$6.39
7
SPRING-COMP .025X.3, 40.5#
1800128
$10.39
8
RING, SNAP 1.0 ID
1800041
$7.27
8
RING, SNAP 1.0 ID
1800041
$7.27
9
O-RING BODY LOOP
1800030
$2.02
9
O-RING BODY LOOP
1800030
$2.02
10
WIPER
1800034
$31.99
11
NUT, CRIMP (CASTLE) 7/16
1800164
$9.59
12
BUMP STOP, MCU, 2.0Dia x 1.75L (ISC 140174-N)
1800859
$77.44
13
BODY, MONOTUBE CO, 2.0 x 14.285L Hard CLEAR
1800860
$289.99
14
BRIDGE, WIDE 2.0 WER ADJUSTER (CLEAR)
1800921
$137.93
15
NEEDLE,1PC, PRESS IN
1800861
$59.99
16
CAP, WIPER 2.0 PRESS IN (CLEAR ANODIZE)
1800794
$49.99
17
CLICKER KNOB (BLACK)
1800418
$89.03
18
IFP PISTON ASM 1.750 W BLEED
1800739
$44.99
19
ASM. CLICKER STUD
1800758
$29.99
20
ASM. CLICKER PISTON
1800757
$79.99
21
SCREW, HEAD 10/32 BTN
1800357
$3.19
22
SCREW,SET #8-32
1800700
Unavailable
23
SPRING, CENTURY# 11980 DIRT
1800867
$31.99
24
JAMB NUT, 2.0IN ACME (CLEAR)
1800868
$43.99
25
Retaining Ring
1800862
$6.39
26
.0625 X 1.75 ID WIRE RING
1800795
$7.27
27
O-RING 2-226
1800863
$4.79
27
O-RING 2-226
1800863
$4.79
28
O-RING 2-324
1800184
$5.65
29
SPRING RETAINER
5633421
$69.49
30
#8-32 X .500 LOW HEAD SCREW
1800843
$4.79
31
O-RING 2-108
1800864
$4.79
32
SPRING NUT 2in ACME (CLEAR)
1800865
$39.99
33
2 PC PISTON ASM INTERLOCKING (with valving)
1800516
$119.99
34
ASM. SEAL HEAD, 2.0, PRESS- IN, STD SEALS
1800869
$47.99
35
ASM. END CAP 2in (CLEAR)
1800755
$49.99
36
O-RING 2-312
1800810
$3.63
36
O-RING 2-312
1800810
$3.63
37
BEARING HFKS8T-10MM
1800809
$59.99
37
BEARING HFKS8T-10MM
1800809
$59.99
38
5mm ID x 2mm thk. O-RING
-------
Unavailable
39
SHIM, 5/8 X .015 X 1.55
-------
Unavailable
