Polaris RZR TURBO R4 PREMIUM RC (R01) - Z23G4V92AL/BL ENGINE, TURBO, COOLING AND OIL - Z23G4V92AL/BL (C702948) Diagram

#

Description
Price

1

BOLT-BANJO,M12X1.5

2522034

$27.99

2

BOLT-BANJO,M12X1.5-1/4NPT

7052693

$13.59

3

CLIP-P,7/16X.343 HOLE

7081722

$3.99

4

ASM-OIL LINE,SUPPLY

2522444

$99.99

5

HOSE-DRAIN,FORMED

5415727

$31.99

6

CLAMP-HOSE,SPRING,24MM

7081825

$7.99

7

HOSE-COOLANT IN

5416808

$47.99

8

HOSE-OIL COOLER IN,UPPER

5416809

$35.19

9

ASM-COOLANT LINE,IN

2522044

$51.99

10

TEE-COOLANT,IN

7052719

$27.99

11

SCR-SHFL-M6X1.0X12 12.9 SPC SP [QTY 1 EVAP]

7521029

$3.99

12

SCR-HH-M8X1.25X38 10.9 ZPC SPC

7521239

$23.99

13

CLAMP-HOSE,SPRING .81

7081026

$7.99

14

ASM-COOLANT LINE,OUT

2522043

$55.99

15

WASHER-COPPER SEALING

7556937

$2.39

16

PLUG-HEX SCKT,W/O-RING,M10X1

7052640

$7.19

17

SCR-10-24X1/2 PH/TX/TRIRD/SEMB

7518176

$4.79
