Polaris RZR TRAIL S 900 60 INCH ALL OPTIONS (R03) - Z20ASA87B2/E87BH/BW/LW SUSPENSION, FRONT SHOCK INTERNALS - Z20ASE87BH/BW/LW (702442) Diagram

#

Description
Price

-

SHOCK-FRONT,2 RESVR,PIGGYBK,LH [INCL ALL]

7044903

$949.99

-

SHOCK-FRONT,2 RESVR,PIGGYBK,RH [INCL ALL]

7044904

$949.99

1

SHAFTLOOP .625 THD (CLEAR)

1800792

$179.99

2

IFP PISTON ASM 1.750 W BLEE

1800739

$44.99

3

12.150L SHAFT-CHROME NEEDLE

----

Unavailable

4

BODY, MONOTUBE CO, 2.0 x 14.825L OA (HARD CLEAR)

----

Unavailable

5

NEEDLE,1PC, PRESS IN

1800861

$64.99

6

#8-32 X .500 LOW HEAD SCRE

1800843

$4.76

7

O-RING 2-226

1800863

$4.76

7

O-RING 2-226

1800863

$4.76

8

O-RING 2-108

1800864

$4.76

9

Retaining Ring

1800862

$6.35

10

RING, SNAP 1.0 ID

1800041

$8.08

10

RING, SNAP 1.0 ID

1800041

$8.08

11

O-RING 2-324

1800184

$5.65

12

O-RING BODY LOOP

1800030

$1.37

12

O-RING BODY LOOP

1800030

$1.37

13

RETAINING RING WIRE .0625 X 1.750ID

1800795

$8.08

14

WIPER

1800034

$36.41

15

NUT, CRIMP (CASTLE) 7/16

1800164

$9.52

16

Res Body, 2.0", 5.0L (Hard Clea1

1800392

Unavailable

17

RING, SNAP 1.750ID

1800159

$5.56

18

BALL, DETENT 3/16"

1800127

$6.46

19

SPRING-COMP .025X.3, 40.5#

1800128

$11.32

20

ASM. CLICKER STUD

1800758

$29.99

21

CLICKER KNOB (BLACK)

1800418

$63.24

22

SCREW, HEAD 10/32 BTN

1800357

$2.19

23

ASM. CLICKER PISTON

1800757

$84.99

24

BEARING HFKS8T-10MM

1800809

$59.99

24

BEARING HFKS8T-10MM

1800809

$59.99

25

CAP, WIPER 2.0 PRESS IN (CLEAR ANODIZE)

1800794

$54.99

26

BRIDGE 2.0 WER ADJUSTER (CLEAR)

1800866

$124.99

27

JAMB NUT, 2.0IN ACME (CLEAR)

1800868

$52.37

28

SPRING ADJUSTER 2.0 Acme (CLEAR)

1800802

$43.56

29

Retainer, Spring Supplied by Polaris

1501194

$59.52

30

BUMP STOP, MCU, 2.0Dia x 1.75L (ISC 140174-N)

1800859

$82.29

31

320126-0 bleed Piston Assembl

1800604

$129.99

32

ASM. SEAL HEAD, 2.0 PRESS IN, BUMPER

----

Unavailable

32

ASM. SEAL HEAD, 2.0 PRESS IN, BUMPER

----

Unavailable

33

ASM. END CAP 2in (CLEAR)

1800755

$49.99

34

SPACER, 1.45 X 2.365L .144 BLEED

----

Unavailable

35

O-RING 2-312

1800810

$3.63

35

O-RING 2-312

1800810

$3.63

36

5mm ID x 2mm thk. O-RING

----

Unavailable
