- RZR PRO R ULTIMATE (R01) - Z24RGD2KAH/AL/BH/BL
ELECTRICAL, WIRE HARNESS, CHASSIS - Z24RGD2KAH/AL/BH/BL (C703249)
Polaris RZR PRO R ULTIMATE (R01) - Z24RGD2KAH/AL/BH/BL ELECTRICAL, WIRE HARNESS, CHASSIS - Z24RGD2KAH/AL/BH/BL (C703249) Diagram
#
Description
Price
1
HARN-CHASSIS,ULT,PROR [INCL. ALL]
2416685
$1,526.79
2
STRAP-CABLE TIEW/EDGECLIP3-6MM
7082073
$27.99
3
CLIP FIR-TREE,DIA6-33MM
7081496
$4.79
4
CLIP-XMAS,6.35MM HOLE,TAPE-ON
7082411
$3.19
5
CLIP-EDGE,1-3MM,6-45MM,SERT.
7081808
$5.59
6
CLIP-EDGE,DIA5-50MM,OUT-SER
7081824
$12.79
7
CLIP-EDGE,1-3MM THICKNESS
7082428
$4.79
8
LABEL-FUSE BOX
7197503
Unavailable
9
COVER-DIAGNOSTIC,W/CLIP
4012170
$8.08
10
RESISTOR-24.9KOHM
2415215
$8.79
11
RESISTOR-4.75KOHM
2415214
$8.79
12
RESISTOR-1.6KOHM
2415213
$8.79
13
FUSE - 7.5, MINI BLADE (BROWN)
4011068
Unavailable
14
FUSE-15AMP,MINI BLADE
4010859
$7.19
15
RELAY-SPST,12V,20A,EPXY,HFA
4016819
$32.37
16
FUSE-IGNITION,10 AMP
2434016
$4.79
17
FUSE-ZCASE, 200A
4018415-200
$37.39
18
FUSE-MCASE,50A
4018414-50
$9.59
19
FUSE-MCASE,SLOTTED,30A
4018414-30
$7.19
20
FUSE-PDM
4017598
$57.19
21
LABEL-PDM,RZR,G4
7191499
Unavailable
22
CLIP- EDGE, 1-3MM THICKNESS
7082427
$5.59
23
DIODE-6AMP
4011474
$40.46
24
GROMMET - 65 MM, BLK
5813954
$7.19
25
ANTENNA,GPS,EXT
4018662
$111.99
26
RESISTOR - EVAP PULLUP - 1 KOHM
2414716
$8.79
27
CLIP, EDGE, HARNESS
7081890
$10.39
28
CAP - VINYL, 125X375, BLACK
5438230
$5.59
29
CABLE-TIE,DIA2.5-34MM,FIR-TREE
7082003
$3.19
30
CLIP - ROUTING, DIN BOX
7082020
$5.59
31
CLIP-EDGE, 1-3mm THICKNESS
7082403
$4.79
32
LED - PANEL MNT, 12V, BLUE
2413217
$51.99
