05- Reverse
Sea-doo RXT iS 255, 2009 05- Reverse Diagram
#
1
IBR Actuator
278002321
Unavailable
2
Hex. Screw M8 X 60, Scotch Grip
250000187
$4.44
3
Stainless, Flat Washer 8 mm
234081600
$0.55
4
LH Support Plate Ass'y | Includes 6 to 7
268000067
$24.99
5
LH FORMED SEAL - Call your local BRP dealership
268000046
Unavailable
6
Plaque Fixation*Fixing Plate | Includes 8 to 9 This part replaces 268000069.
268000133
$42.99
7
LH FORMED SEAL - Call your local BRP dealership
268000055
Unavailable
8
RH SUPPORT PLATE ASS'Y - Call your local BRP dealership | Includes 10 to 11
268000068
Unavailable
9
RH FORMED SEAL - Call your local BRP dealership
268000047
Unavailable
10
Plaque Fixation*Fixing Plate | Includes 12 to 13 This part replaces 268000070.
268000135
$38.99
11
RH FORMED SEAL - Call your local BRP dealership
268000056
Unavailable
12
Hex. Screw M8 X 30, Scotch Grip
207383060
$1.90
13
Flat Washer M8.5 x 18
293050001
$3.07
14
WASHER - Call your local BRP dealership
268000065
Unavailable
15
BLACK ''U'' ARM - Call your local BRP dealership
271001615
Unavailable
16
TIGHTE BUSHING - Call your local BRP dealership
268000057
Unavailable
17
Hex. Screw M8 X 20, Scotch Grip
207382060
$1.99
18
Flat Washer 8 mm, Stainless
234082600
$2.43
19
SPACER - Call your local BRP dealership
268000062
Unavailable
20
Linkage Arm
268000145
$18.99
21
Hex. Screw M8 X 45
207084560
$3.38
22
Stainless, Flat Washer 8 mm
234081600
$0.55
23
Venturi Bushing
271000321
$8.69
24
Hex. Elastic Nut M8 Brass
232581200
$2.22
25
TRIMMING RING, BLACK - Call your local BRP dealership
268000155
Unavailable
26
Venturi Bushing
293900007
$5.45
27
Spacer
268000063
$18.49
28
Flat Washer 8 mm, Stainless
234082600
$2.43
29
Venturi Bushing
293900007
$5.45
30
HEX. SCREW M8 X 70 - Call your local BRP dealership
207087060
Unavailable
31
Friction Sleeve
268000045
$9.89
32
Socket Head Screw M6 X 16, Scotch Grip
205561660
$1.68
33
Jet Pump Nozzle
267000727
$77.99
34
Nozzle Lever, Black
268000148
$61.99
35
Direction Lever Arm
268000058
$13.99
36
Spacer
268000060
$12.99
37
Flat Washer M6, Stainless
234062600
$0.77
38
Hex. Screw M6 X 20, Scotch Grip
207362060
$1.47
39
Socket Head Screw M8 X 10, Scotch Grip
211000127
$3.99
40
Spacer
268000060
$12.99
41
Bushing
268000059
$14.17
42
Flat Washer M6, Stainless
234062600
$0.77
43
Hex. Screw M6 X 20, Scotch Grip
207362060
$1.47
44
Reverse Gate Ass'y
268000048
Unavailable
45
Stainless Flat Washer M6
234061600
$0.33
46
Socket Head Screw M6 X 16, Scotch Grip
205561660
$1.68
47
Spacer
271001039
$16.49
48
Flat Washer 8 mm, Stainless
234082600
$2.43
49
Hex. Screw M8 X 30, Scotch Grip
207383060
$1.90
50
Guard
268000162
$29.99
51
Hex. Flange Screw M6.81 X 25, Plastite
243162560
$2.19
52
Silicone Sealant 51388, 300 ml
296000309
$36.99
53
Loctite 243, 10 ml
293800060
$21.49
