Sea-doo RXT aS X & aS XRS 260, 2011 Seat Suspension 1 Diagram

#

Description
Price

1

FRONT ARM ASS'Y - Call your local BRP dealership | Includes 41 to 41d

279000308

Unavailable

2

Bushing

279000019

$24.99

3

PIVOT TUBE - Call your local BRP dealership

279000038

Unavailable

4

PIVOT TUBE - Call your local BRP dealership

279000041

Unavailable

5

FRONT ARM BASE - Call your local BRP dealership

279000167

Unavailable

6

LH CLAMP - Call your local BRP dealership

279000089

Unavailable

7

RH CLAMP - Call your local BRP dealership

279000092

Unavailable

8

RUBBER BUMPER - Call your local BRP dealership

279000047

Unavailable

9

Socket Head Screw M8 X 20, Scotch Grip

205582060

$4.44

10

Hex. Screw M8 X 30, Scotch Grip

207383060

$1.90

11

Flat Washer M8, Stainless

234080600

$1.48

34

Mount Dart

293730040

$1.04

35

Not Available As Spare Parts

XXX

Unavailable

36

Not Available As Spare Parts

XXX

Unavailable

37

Not Available As Spare Parts

XXX

Unavailable

72

Not Available As Spare Parts

XXX

Unavailable

73

Not Available As Spare Parts

XXX

Unavailable

85

BRACKET - Call your local BRP dealership

279000155

Unavailable

86

Hex. Screw M6 X 20, Scotch Grip

207362060

$1.47

87

Stainless Flat Washer M6

234061600

$0.33

93

Hex. Screw M8 X 30, Scotch Grip

250000526

$0.77

94

Flat Washer

279000336

$11.57

95

RUBBER BUMPER - Call your local BRP dealership

279000047

Unavailable

96

FOOT REST - Call your local BRP dealership

279000306

Unavailable

97

Hex. Screw M10 X 110, Scotch Grip

230201060

$14.21

98

Flat Washer

211200051

$1.68

99

Hex. Screw M6 X 20, Scotch Grip

207362060

$1.47

100

Flat Washer M6

250200115

$3.28

104

Lateral Bellows

279000009

$80.99

105

Retaining Ring

279000011

$18.99

106

Pop Rivet 3/16"

293150176

$2.39

107

Oetiker Gear Clamp

293650199

$9.69

134

RUBBER BUMPER - Call your local BRP dealership

279000193

Unavailable

135

Retaining Ring

279000115

$14.49

136

Pop Rivet 3/16"

293150005

$0.52
