Description

Price

1

Hex. Screw M8 X 40

207184060

$1.85

2

Hex. Screw M10 X 20, Scotch Grip

207302060

$3.29

3

Hex. Screw M6 X 12, Scotch Grip

207361260

$0.48

4

Elastic Stop Nut M6, Brass

232561200

$3.51

5

Flat Washer 10 mm, Stainless

234000600

$1.07

6

Stainless Flat Washer M6

234061600

$0.25

7

Flat Washer 8 mm, Stainless

234082600

$1.98

8

Battery, 30 Amperes

278001882

$152.72

9

Battery Ground Cable

278003269

$33.77

10

Cable-Starter

278003398

$50.02

11

Throttle Position Sensor

278002283

$94.22

12

LH Throttle Sensor

278002284

$115.35

13

Battery Support

278003306

$14.92

14

Switch RH Mode/Set

278002602

$100.72

15

Switch Start/Stop This part replaces 278002676.

278002676

Unavailable

16

Switch LH VTS/Sport/Eco | Package STD

278002767

$101.37

17

Not Available As Spare Parts

XXX

Unavailable

18

Housing JAE 2 Circuits

278002856

$13.83

19

Wiring Harness | Includes 101 To 2057

278002941

$712.37

20

Wiring Harness Ass'y

278002950

$360.07

21

Safety Nut (DESS Switch)

278002963

$2.72

23

Support

278003048

$17.52

25

Tie Rap 300mm

293750053

$2.75

26

Battery Bolt Kit

250000282

$2.95

27

Tie-Rap 180 mm

414115200

$0.09

28

Starter Relay

278003012

$35.07

29

Diagnostic Connector

278002704

$15.57

30

Tie Wrap 368 mm

293750008

$0.85

31

LCD Gauge | Model GTX LTD S 260

278003380

$746.17

32

O.T.A.S Actuator

278003537

$33.12

33

O.T.A.S. Sensor

278003008

$86.42

34

Safety Lanyard, Antitheft

278002483

$68.87

34

Safety Lanyard, Learning Key

278002484

$45.47

35

Voltage Regulator | For replacement, refer to service bulletin 2005-5

710001103

$118.92

36

O.T.A.S. Sensor Ass'y

278003009
